INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
ELECTRICAL EQUIPMENT FOR MEASUREMENT,
CONTROL AND LABORATORY USE –
EMC REQUIREMENTS –
Part 2-5: Particular requirements –
Test configurations, operational conditions and performance criteria
for field devices with field bus interfaces according to IEC 61784-1

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 61326-2-5 has been prepared by subcommittee 65A: System
aspects, of IEC technical committee 65: Industrial-process measurement, control and
automation.
This second edition cancels and replaces the first edition published in 2006. This edition
constitutes a technical revision.

– 4 – 61326-2-5 © IEC:2012
The main technical changes with regard to the previous edition are as follows:
– Update with respect to IEC 61326-1:2012.
The text of this standard is based on the following documents:
FDIS Report on voting
65A/643/FDIS 65A/654/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.
This part of IEC 61326 series is to be used in conjunction with IEC 61326-1:2012 and follows
the same numbering of clauses, subclauses, tables and figures.
When a particular subclause of IEC 61326-1 is not mentioned in this part, that subclause
applies as far as is reasonable. When this standard states “addition”, “modification” or
“replacement”, the relevant text in IEC 61326-1 is to be adapted accordingly.
NOTE The following numbering system is used:
– subclauses, tables and figures that are numbered starting from 101 are additional to those in
IEC 61326-1;
– unless notes are in a new subclause or involve notes in IEC 61326-1, they are numbered starting from 101
including those in a replaced clause or subclause;
– additional annexes are lettered AA, BB, etc.
A list of all parts of IEC 61326 series, under the general title Electrical equipment for
measurement, control and laboratory use – EMC requirements can be found on the IEC
website.
The committee has decided that the contents of this publication will remain unchanged until
the stability date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
61326-2-5 © IEC:2012 – 5 –
ELECTRICAL EQUIPMENT FOR MEASUREMENT,
CONTROL AND LABORATORY USE –
EMC REQUIREMENTS –
Part 2-5: Particular requirements –
Test configurations, operational conditions and performance criteria
for field devices with field bus interfaces according to IEC 61784-1

1 Scope
In addition to the requirements of International Standard IEC 61326-1, this part of IEC 61326
treats the particular features for EMC testing of field devices with field bus interfaces. This
part of IEC 61326 covers only the field bus interface of the equipment.
NOTE The other functions of the equipment remain covered by other parts of IEC 61326 series.
This part refers only to field devices intended for use in process control and process
measuring.
In this standard field devices with interfaces according to IEC 61784-1, CP 3/2 and CP 1/1 as
defined in IEC 61784 are covered. Other field busses may be included in future editions of
this standard.
The IEC 61784-1 specifies a set of protocol specific communication profiles based on
IEC 61158.
The manufacturer specifies the environment for which the product is intended to be used
and/or selects the appropriate test level specifications of IEC 61326-1.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and
are indispensable for its application. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any
amendments) applies.
Clause 2 of IEC 61326-1 applies except as follows:
Addition:
IEC 61158-2:2010, Industrial communication networks – Fieldbus specifications – Part 2:
Physical layer specification and service definition
IEC 61158-3-3:2007, Industrial communication networks – Fieldbus specifications – Part 3-3:
Data-link layer service definition – Type 3 elements
IEC 61158-5-5:2007, Industrial communication networks – Fieldbus specifications – Part 5-5:
Application layer service definition – Type 5 elements
IEC 61158-6-10:2010, Industrial communication networks – Fieldbus specifications – Part 6-
10: Application layer protocol specification – Type 10 elements

– 6 – 61326-2-5 © IEC:2012
IEC 61784-1:2010, Industrial communication networks – Profiles – Part 1: Fieldbus profiles
3 Terms and definitions
Clause 3 of IEC 61326-1 applies.
4 General
Clause 4 of IEC 61326-1 applies.
5 EMC test plan
5.1 General
Subclause 5.1 of IEC 61326-1 applies.
5.2 Configuration of EUT during testing
Subclause 5.2 of IEC 61326-1 applies, except as follows:
Addition:
Additional requirements: see Annexes AA and BB.
5.3 Operation conditions of EUT during testing
Subclause 5.3 of IEC 61326-1 applies, except as follows:
Addition:
Additional requirements: see Annexes AA and BB.
5.4 Specification of functional performance
Subclause 5.4 of IEC 61326-1 applies.
5.5 Test description
Subclause 5.5 of IEC 61326-1 applies.
6 Immunity requirements
6.1 Conditions during the tests
Subclause 6.1 of IEC 61326-1 applies.
6.2 Immunity test requirements
Subclause 6.2 of IEC 61326-1 applies.
6.3 Random aspects
Subclause 6.3 of IEC 61326-1 applies.

61326-2-5 © IEC:2012 – 7 –
6.4 Performance criteria
Subclause 6.4 of IEC 61326-1 applies, except as follows:
Addition:
Additional requirements: see Annexes AA and BB.
7 Emission requirements
Clause 7 of IEC 61326-1 applies.
8 Test results and test report
Clause 8 of IEC 61326-1 applies, except as follows:
Addition:
The type of shield connection at the EUT shall be stated in the test report.
9 Instructions for use
Clause 9 of IEC 61326-1 applies.

– 8 – 61326-2-5 © IEC:2012
Annex AA
(normative)
Particular requirements –
Test configurations, operational conditions and performance criteria for
field devices with field bus interfaces according to IEC 61784-1 CP 1/1

AA.1 General
In connection with the main part of this standard, this Annex AA describes specific test
configurations, operational conditions and performance criteria regarding the field bus
interface using the communication profile CP 1/1 according to IEC 61784-1.
To prevent confusion with requirements of other annexes, the equipment under test (EUT) is
called “EUT with CP 1/1 interface” throughout this annex.
AA.2 EMC test plan
AA.2.1 Configuration of EUT with CP 1/1 interface during testing
Subclause 5.2 of IEC 61326-1 applies, except as follows:
Addition:
AA.2.1.1 Test configuration for EUT with CP 1/1 interface
In order to assign any malfunction of the communication during the EMC-test to the EUT with
CP 1/1 interface, the configuration of field devices with interfaces according to IEC 61784-1,
CP 1/1 shall be limited to the operation of one host system and one EUT with CP 1/1 interface
during EMC type tests.
Ports other than I/O ports covered by this part of the standard are tested according to
IEC 61326-1.
The connection plan is shown in Figure AA.1.
The field device is connected via a device coupler with the power conditioner and the host
system.
A standardised field bus terminator is attached at the third port of the device coupler.
The EUT with CP 1/1 interface, power conditioner, host system, device coupler(s) and
terminator are connected by means of a standard type A field bus cable (foil shield, foil
shield/mesh). Armoured cables or cables in conduit are not allowed for EMC testing.
Except for the connection at the EUT with CP 1/1 interface itself (see AA.2.1.3), the shield
shall be connected at any individual component by a low-impedance grounding strip
(connection between shield and the case with a large surface).
The individual cable lengths L1, L2, L3, L5 and L6 originate from a practice-adjusted set up,
preferred as given in Figure AA.1.

61326-2-5 © IEC:2012 – 9 –
The cable length L4 should be 8 m ± 1 m, in case that the respective basic standards do not
specify other lengths. The cable installation shall be in accordance with the appropriate basic
standard.
The connection of the shield at the shield grounding point may be produced by partially
removing the insulation of the cable shield and fixing the cable shield with a metal clamp or by
means of conductive leading-in-conductors such as a metallic cable gland at the ground plane
or at the shielding metal wall respectively.
The location and execution of the shield grounding point depend on the given test facility, e.g.
by use of an anechoic chamber or a shielded cabin it is the metal wall penetration; and with
tests on tables with ground plane the shield grounding point is on the ground plane.
AA.2.1.2 Connection cable for EUT with CP 1/1 interface
A standard bus cable type A shall be used as communication cable (see IEC 61158–2:2010,
12.8.2). The cable lengths L1 to L4, are given in Figure AA.1 and additional requirement for
L4 is described in AA.2.1.1. The lengths of L5 and L6 are not specified and depend on the
installed equipment.
AA.2.1.3 Connections at the EUT with CP 1/1 interface
The grounding of the EUT with CP 1/1 interface shall be in accordance with the
manufacturer’s specification.
The shield of the cable shall be connected in the most sensitive method (for example with the
shield not connected at the EUT with CP 1/1 interface) if not otherwise specified by the
manufacturer.
NOTE If the manufacturer specifies the shield shall be connected at the EUT with CP 1/1 interface, the EUT with
CP 1/1 interface shall be tested in accordance with the manufacturer’s specification.
AA.2.1.4 Field bus network
The field bus network shall include the terminator of the bus, device coupler(s), the host
system and the EUT with CP 1/1 interface. For bus-powered devices the field bus network
includes additionally the power conditioner and the power supply. The evaluation and
conditioning of the data in the host system are not the object of this part of the standard. The
device coupler(s) and the bus terminator are passive components only.

– 10 – 61326-2-5 © IEC:2012
G C
L5
4 L2
L1
T
T
E1 E2
2 2
L6
A L3
2a
L4
D
B
2a
IEC  1838/12
A: Host system 1: Shield grounding point (SGP) of L4
B: Field device (EUT with CP 1/1 interface) 2: Shield / housing connected with low impedance
2a: Enclosure connected with low impedance
C: Power conditioner (5 mH+50 Ω)
D: EMC test place 3: Cable from device coupler(s) to SGP
E1, E2: device coupler(s) 4: Terminator, either direct at device coupler or after a
short cable (< 1 m)
T: Bus terminator 5: Cable from SGP to field device
G: Power supply 6: Connection of shield at field device see AA.2.1.3
L1: 8 m cable type A 7: A, C, G, E1 and T may be included in a single
housing / system / device
L2: 2 m cable type A L3: 2 m cable type A
L4: 8 m cable type A (see AA.2.1.2) L5, L6: cable type A (see AA.2.1.2)
Figure AA.1 – Test set up for EUT with CP 1/1 interface
AA.2.2 Operation conditions of EUT with CP 1/1 interface during testing
Subclause 5.3 of IEC 61326-1 applies, except as follows:
Addition:
61326-2-5 © IEC:2012 – 11 –
AA.2.2.1 Operational conditions for EUT with CP 1/1 interface
a) The macrocyle of the field bus segment should be as short as possible to have as often as
possible communication on the bus and to have fast reaction of the system.
b) For a transmitter type device there shall be a Publisher Subscriber communication
relationship for each process value and its status (e.g. output parameter of AI or DI) that
the EUT with CP 1/1 interface offers. The EUT with CP 1/1 interface has the role
‘Publisher’.
c) For a receiver type device there shall be:
– a Publisher Subscriber communication relationship for each setpoint/input value and its
status (e.g. input parameter of AO or DO) that the EUT with CP 1/1 interface accepts;
in this/these relationship(s) the EUT with CP 1/1 interface has the role ‘Subscriber’;
– and a Publisher Subscriber communication relationship for each output value and its
status (e.g. BKCAL_OUT/BKCAL_OUT_D) that the EUT with CP 1/1 interface offers; in
this/these relationship(s) the EUT with CP 1/1 interface has the role ‘Publisher’.
d) The “Stale Count Limit” has to be set to 2.
In cases where the “Stale count Limit” is not adjustable the value (not equal to 2) shall be
stated in the test report.
e) The frequency of client-server communication has to be set to one service request (e.g.
read request) every other macrocyle.
AA.2.2.2 Status for EUT with CP 1/1 interface
The host system monitors the received data of the EUT with CP 1/1 interface. The received
data is of the data type QualifiedFloat32 or QualifiedUnsigned8 as defined in
IEC 61158-5-5:2007, 5.3.3.12 resp. 5.3.3.13. Those data types are of the format
STRUCTURE and have a field named status.
For the automation system and the test evaluation the quality in the status is significant.
In case of received data only four qualities can appear (extract from IEC 61158-6-10:2010,
5.1.1.3.2.2):
– "Good (Cascade)" means status is in the range between 192 and 255
– "Good (Non Cascade)" means status is in the range between 128 and 191
– "Uncertain"  means status is in the range between 64 and 127
– "Bad"  means status is in the range between 0 and 63
The equipment under test shall preferably be configured so that the value of the status is 128
or greater during normal operation without EMC disturbance.
Other values for the status are allowed if they enable the evaluation the function of the EUT
with CP 1/1 interface. However values of the status indicating a disturbed communication
shall be avoided. If a status value deviating from 128 is chosen the reasons for this decision
have to be reported in the test report.
AA.2.2.3 Monitoring for EUT with CP 1/1 interface
a) For transmitter type device:
The process value(s) and its status shall be monitored.
The requirements for Pass / Fail the EMC test with regard to the value(s) are given in the
specification of the manufacturer or in an appropriate part of this IEC 61326 standard
series.
b) For receiver type device (Positioner, Displays):
The output value (e.g. BKCAL_OUT/BKCAL_OUT_D) and its status shall be monitored.
For devices like positioner or valves or displays: Visual confirmation is required. The

– 12 – 61326-2-5 © IEC:2012
requirements for Pass / Fail the EMC test with regard to the value(s) are given in the
specification of the manufacturer or in an appropriate part of this IEC 61326 standard
series.
c) The number of consecutive non-responses of the client-server communications shall be
counted. Any count more than 2 consecutive non-responses shall be considered as a
communication failure.
d) Any overrun of the stale counter shall be considered as a failure.
AA.3 Performance criteria
Subclause 6.4 of IEC 61326-1 applies, except as follows:
Performance criterion A is extended by the following:
Performance criteria A
No communication failures are detected (see AA.2.2.3). The status value chosen
according to AA.2.2.2 shall remain unchanged during and after the test (see AA.2.2.2
and AA.2.2.3).
Performance criterion B is extended by the following:
Performance criteria B
The status value (see AA.2.2.2 and AA.2.2.3) deviates during the test, but returns to
normal afterwards and/or communication failure is detected but after test the device
returns with no operator intervention to the expected operational state.
Performance criterion C is extended by the following:
Performance criteria C
The status value (see AA.2.2.2 and AA.2.2.3) deviates during the test, and/or
communication failures are detected, but after test the device only returns with
operator intervention to the intended operation mode.
AA.4 Information on the host system
The host system includes the following functionality:
a) Configures the communication relationships as described in AA.2.2.1
b) Monitors the communication, it detects / counts communication errors and violation of
status values as described in AA.2.2.3.
c) Initiates the communication in Client Server communication relationships
d) Has the role of the LAS (Link Active Scheduler)
NOTE If the EUT with CP 1/1 interface is a transmitter type device the host system needs to play the role of a
receiver type device (see AA.2.2.3 a). If the EUT with CP 1/1 interface is a receiver type device then the host
system needs to be the transmitter and also be able to monitor the output of the EUT with CP 1/1 interface
(see AA.2.2.3 b).
61326-2-5 © IEC:2012 – 13 –
Annex BB
(normative)
Particular requirements –
Test configurations, operational conditions and performance criteria for
field devices with field bus interfaces according to IEC 61784-1 CP 3/2

BB.1 General
In connection with the main part of this standard, this Annex BB describes specific test
configurations, operational conditions and performance criteria regarding the field bus
interface using the communication profile CP 3/2 according to IEC 61784-1.
To prevent confusion with requirements of other annexes, the equipment under test (EUT) is
called “EUT with CP 3/2 interface” throughout this annex.
BB.2 EMC test plan
BB.2.1 Configuration of EUT with CP 3/2 interface during testing
Subclause 5.2 of IEC 61326-1 applies, except as follows:
Addition:
BB.2.1.1 Test configuration for EUT with CP 3/2 interface
In order to assign any malfunction of the communication during the EMC-test to the EUT with
CP 3/2 interface, the configuration of field devices with interfaces according to IEC 61784-1,
CP 3/2 shall be limited to the operation of one master and one slave (EUT with CP 3/2
interface) during EMC type tests.
Auxiliary connections for power supply or signalling are possible for the EUT with CP 3/2
interface.
The connection plan is shown in Figure BB.1.
The EUT with CP 3/2 interface is connected via a device coupler with the signal coupler. The
signal coupler is connected to the Automation system.
A standardised field bus terminator is attached at the third port of the field device coupler.
The components EUT with CP 3/2 interface, signal coupler, device coupler and terminator are
connected by standardised field bus cables.
The shield shall be connected at any individual component by a low-impedance grounding
strip (connection between shield and the case with a large surface).
The individual cable lengths L1, L2, L3 originate from a practice-adjusted set up, preferred as
given in Figure BB.1.
The cable length L4 should be 8 m ± 1 m, in case that the respective basic standards do not
specify other lengths. The cable installation shall be in accordance with the appropriate basic
standard.
– 14 – 61326-2-5 © IEC:2012
The connection of the shield at the shield grounding point may be produced by partially
removing the isolation of the cable shield and fixing the cable shield with a metal clamp or by
means of conductive leading-in-conductors such as a metallic cable gland at the ground plane
or at the shielding metal wall respectively.
The location and execution of the shield grounding point depend on the given test facility, e.g.
by use of an anechoic chamber or a shielded cabin it is the metal wall penetration; and with
tests on tables with ground plane the shield grounding point is on the ground plane.
BB.2.1.2 Connection cable for EUT with CP 3/2 interface
A standard bus cable type A shall be used as communication cable (see IEC 61158–2:2010,
11.8.2). The cable lengths L1 to L3 are given in Figure BB.1 and L4 is described in BB.2.1.1.
BB.2.1.3 Connections at the EUT with CP 3/2 interface
The grounding of the EUT with CP 3/2 interface and the shield connections shall be in
accordance with the manufacturer’s specification.
BB.2.1.4 Field bus network for EMC test for EUT with CP 3/2 interface
The field bus network includes the terminator of the bus, a device coupler, a signal coupler,
the automation system and the EUT with CP 3/2 interface.
The evaluation and conditioning of the data in the signal coupler and in the automation
system are not the object of this part of the standard.
The device coupler and the bus terminator are passive components only.

61326-2-5 © IEC:2012 – 15 –
L5
L1 L2
A
C T 4
2 2
E
L3
2a
L4
D
B
2a
IEC  1839/12
A: Automation system (master) 1: Shield grounding point (SGP) of L4
B: EUT with CP 3/2 interface (slave) 2: Shield / housing connected with low impedance
C: Signal coupler 2a: Enclosure connected with low impedance
D: EMC test place 3: Connection see BB.1.1.3
E: Device coupler 4: Terminator, either direct at device coupler or after a
short cable (< 1 m)
T: Bus terminator 5: Cable from SGP to field device
L1: 8 m cable type A 6: Connection of shield at field device see BB.2.1.3
L2: 2 m cable type A 7: A and C may be included in a single housing / system
/ device
L3: 2 m cable type A L4: 8 m cable type A (see BB.2.1.2)
L5: Cable type A (see BB.2.1.2)
Figure BB.1 – Test set up for EUT with CP 3/2 interface

– 16 – 61326-2-5 © IEC:2012
BB.2.2 Operation conditions of EUT with CP 3/2 interface during testing
Subclause 5.3 of IEC 61326-1 applies, except as follows:
Addition:
BB.2.2.1 Operational conditions for EUT with CP 3/2 interface
The operating conditions describe the software settings at the EUT with CP 3/2 interface and
at the automation system. The master connected to the signal coupler is set as "master class
1", the EUT with CP 3/2 interface as "slave".
The cyclic operating mode shall be used.
The parameter "retry limit" shall be set to 2 at the master. This means after three consecutive
transmission errors (bus-line break down or slave not working) the master (automation
system) set the status to "0".
The general bus parameters for the cyclic data exchange in IEC 61158-3-3:2007, 5.5.2.3.3,
Table 29 shall be taken into account.
BB.2.2.2 Status for EUT with CP 3/2 interface
The field bus controller in conjunction with the automation system monitors the received data
of the EUT with CP 3/2 interface. The received data is of the data type QualifiedFloat32 or
QualifiedUnsigned8 as defined in IEC 61158-5-5:2007, 5.3.3.12 resp. 5.3.3.13. Those data
types are of the format STRUCTURE and have a field named status.
For the automation system and the test evaluation the quality in the status is significant.
In case of received data only four qualities can appear (extract from IEC 61158-6-10,
5.1.1.3.2.2):
– "Good (Cascade)" means status is in the range between 192 and 255
– "Good (Non Cascade)" means status is in the range between 128 and 191
– "Uncertain"  means status is in the range between 64 and 127
– "Bad"  means status is in the range between 0 and 63
The equipment under test shall preferably be configured so that the value of the status is 128.
Other values for the status are allowed if they enable the evaluation the function of the EUT
with CP 3/2 interface. However values of the status indicating a disturbed communication
shall be avoided. If a status value deviating from 128 is chosen the reasons for this decision
have to be reported in the test report.
BB.2.2.3 Monitoring for EUT with CP 3/2 interface
a) The status shall be monitored.
b) The measuring value shall be monitored.
If the allowed tolerances are not specified in an appropriate part of this standard the
values specified by the manufacturer may be used.
BB.3 Performance criteria
Subclause 6.4 of IEC 61326-1 applies, except as follows:
Performance criterion A is extended by the following:

61326-2-5 © IEC:2012 – 17 –
Performance criteria A
The status value as described in BB.2.2.2 shall remain unchanged during and after the
test (see BB.2.2.2 and BB.2.2.3).
Performance criterion B is extended by the following:
Performance criteria B
The status value (see BB.2.2.2 and BB.2.2.3) deviates during the test, but returns to
the same status value as before the test with no operator intervention.
Performance criterion C is extended by the following:
Performance criteria C
The status value (see BB.2.2.2 and BB.2.2.3) deviates during the test, but after test
the device only returns with operator intervention to the intended operation mode.

___________
– 18 – 61326-2-5 © CEI:2012
SOMMAIRE
AVANT-PROPOS . 19
1 Domaine d’application . 21
2 Références normatives . 21
3 Termes et définitions . 22
4 Généralités . 22
5 Plan d’essais de CEM . 22
5.1 Généralités . 22
5.2 Configuration de l’EUT pendant les essais . 22
5.3 Conditions de fonctionnement de l’EUT pendant les essais . 22
5.4 Spécification de l'aptitude à la fonction . 22
5.5 Description de l’essai . 22
6 Exigences relatives à l’immunité . 22
6.1 Conditions pendant les essais . 22
6.2 Exigences pour les essais d’immunité . 22
6.3 Aspects aléatoires . 23
6.4 Critères d'aptitude à la fonction . 23
7 Exigences relatives à l’émission . 23
8 Résultats d’essai et rapport d’essai . 23
9 Instructions d’utilisation . 23
Annexe AA (normative) Exigences particulières – Configurations d’essai, conditions
de fonctionnement et critères d’aptitude à la fonction pour les équipements de terrain
utilisant des interfaces de bus de terrain conformes à la CEI 61784-1 CP 1/1 . 24
Annexe BB (normative) Exigences particulières – Configurations d’essai, conditions de
fonctionnement et critères d’aptitude à la fonction pour les équipements de terrain
avec des interfaces de bus de terrain conformes à la CEI 61784-1, CP 3/2 . 29

Figure AA.1 – Montage d'essai pour EUT avec interface CP 1/1 . 26
Figure BB.1 – Montage d'essai pour EUT avec interface CP 3/2 . 31

61326-2-5 © CEI:2012 – 19 –
COMMISSION ÉLECTROTECHNIQUE INTERNATIONALE
____________
MATÉRIEL ÉLECTRIQUE DE MESURE, DE COMMANDE ET DE
LABORATOIRE – EXIGENCES RELATIVES À LA CEM –

Partie 2-5: Exigences particulières –
Configurations d'essai, conditions de fonctionnement et critères
d’aptitude à la fonction pour les équipements de terrain avec des
interfaces utilisant des bus de terrain conformes à la CEI 61784-1

AVANT-PROPOS
1) La Commission Electrotechnique Internationale (CEI) est une organisation mondiale de normalisation
composée de l'ensemble des comités électrotechniques nationaux (Comités nationaux de la CEI). La CEI a
pour objet de favoriser la coopération internationale pour toutes les questions de normalisation dans les
domaines de l'électricité et de l'électronique. A cet effet, la CEI – entre autres activités – publie des Normes
internationales, des Spécifications techniques, des Rapports techniques, des Spécifications accessibles au
public (PAS) et des Guides (ci-après dénommés "Publication(s) de la CEI"). Leur élaboration est confiée à des
comités d'études, aux travaux desquels tout Comité national intéressé par le sujet traité peut participer. Les
organisations internationales, gouvernementales et non gouvernementales, en liaison avec la CEI, participent
également aux travaux. La CEI collabore étroitement avec l'Organisation Internationale de Normalisation (ISO),
selon des conditions fixées par accord entre les deux organisations.
2) Les décisions ou accords officiels de la CEI concernant les questions techniques représentent, dans la mesure
du possible, un accord international sur les sujets étudiés, étant donné que les Comités nationaux de la CEI
intéressés sont représentés dans chaque comité d’études.
3) Les Publications de la CEI se présentent sous la forme de recommandations internationales et sont agréées
comme telles par les Comités nationaux de la CEI. Tous les efforts raisonnables sont entrepris afin que la CEI
s'assure de l'exactitude du contenu technique de ses publications; la CEI ne peut pas être tenue responsable
de l'éventuelle mauvaise utilisation ou interprétation qui en est faite par un quelconque utilisateur final.
4) Dans le but d'encourager l'uniformité internationale, les Comités nationaux de la CEI s'engagent, dans toute la
mesure possible, à appliquer de façon transparente les Publications de la CEI dans leurs publications
nationales et régionales. Toutes divergences entre toutes Publications de la CEI et toutes publications
nationales ou régionales correspondantes doivent être indiquées en termes clairs dans ces dernières.
5) La CEI elle-même ne fournit aucune attestation de conformité. Des organismes de certification indépendants
fournissent des services d'évaluation de conformité et, dans certains secteurs, accèdent aux marques de
conformité de la CEI. La CEI n'est responsable d'aucun des services effectués par les organismes d
...
