ISO 10300-1:2023
(Main)Calculation of load capacity of bevel gears — Part 1: Introduction and general influence factors
Calculation of load capacity of bevel gears — Part 1: Introduction and general influence factors
This document specifies the methods of calculation of the load capacity of bevel gears, the formulae and symbols used for calculation, and the general factors influencing load conditions. The formulae in this document are intended to establish uniformly acceptable methods for calculating the load-carrying capacity of straight, helical (skew), spiral bevel, Zerol and hypoid gears. They are applicable equally to tapered depth and uniform depth teeth. Hereinafter, the term “bevel gear” refers to all of the gear types; if not, the specific forms are identified. The formulae in this document take into account the known major factors influencing load-carrying capacity. The rating formulae are only applicable to types of gear tooth deterioration, that are specifically addressed in the individual parts of the ISO 10300 series. Rating systems for a particular type of bevel gears can be established by selecting proper values for the factors used in the general formulae. NOTE This document is not applicable to bevel gears which have an inadequate contact pattern under load (see Annex D). The rating system of this document is based on virtual cylindrical gears and restricted to bevel gears whose virtual cylindrical gears have transverse contact ratios of εvα The user is cautioned that when the formulae are used for large average mean spiral angles (βm1 + βm2)/2 > 45°, for effective pressure angles αe > 30° and/or for large facewidths b > 13 mmn, the calculated results of this document should be confirmed by experience.
Calcul de la capacité de charge des engrenages coniques — Partie 1: Introduction et facteurs généraux d'influence
General Information
Relations
Standards Content (Sample)
INTERNATIONAL ISO
STANDARD 10300-1
Third edition
2023-08
Calculation of load capacity of bevel
gears —
Part 1:
Introduction and general influence
factors
Calcul de la capacité de charge des engrenages coniques —
Partie 1: Introduction et facteurs généraux d'influence
Reference number
© ISO 2023
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii
Contents Page
