IEC 61754-36:2025

IEC 61754-36 ®
Edition 1.0 2025-05
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Fibre optic interconnecting devices and passive components – Fibre optic
connector interfaces –
Part 36: Type SAC connector family

Dispositifs d’interconnexion et composants passifs fibroniques – Interfaces de
connecteurs fibroniques –
Partie 36: Famille de connecteurs de type SAC
ICS 33.180.20  ISBN 978-2-8327-0434-9
