EN 50388:2005

EN 50388:2005 is a standard published by CLC. Its full title is "Railway applications - Power supply and rolling stock - Technical criteria for the coordination between power supply (substation) and rolling stock to achieve interoperability". This standard covers: This European Standard is intended to be used to set up the requirements for the acceptance of rolling stock on infrastructure in the field of: - co-ordination of protection principles between power supply and traction units, especially fault discrimination for short-circuits; - co-ordination of installed power on the line and power demand of the trains; - co-ordination of traction unit regenerative braking and power supply receptivity; - co-ordination of harmonic behaviour. This standard deals with the definition and quality requirements of the power supply at the interface between traction unit and fixed installations. The standard specifies the interface between rolling stock and electrical fixed installations for traction, in the frame ”supply system“. The interaction between pantograph and overhead line is dealt with in EN 50367. The interaction with subsystem “control-command” (especially signalling) is not dealt with in the standard. Requirements are given for the following categories of line: - TSI lines (high speed and conventional), - classical lines. For classical lines, values, if any, are given for the existing European networks. A set of values is also specified for the future network, which is named ”target“ network. The following electric traction systems are concerned: - railways; - guided mass transport systems that are integrated with the railways; - material transport systems that are integrated with the railways. This standard does not apply retrospectively to rolling stock already accepted by infrastructure managers. However, on new infrastructure, existing rolling stock may be accepted by the infrastructure manager, provided there is an agreement. Information is given to the train operating companies on electrification parameters to enable them to confirm after consultation with the rolling stock manufacturers that there will be no consequential disturbance on the electrification system.

This European Standard is intended to be used to set up the requirements for the acceptance of rolling stock on infrastructure in the field of: - co-ordination of protection principles between power supply and traction units, especially fault discrimination for short-circuits; - co-ordination of installed power on the line and power demand of the trains; - co-ordination of traction unit regenerative braking and power supply receptivity; - co-ordination of harmonic behaviour. This standard deals with the definition and quality requirements of the power supply at the interface between traction unit and fixed installations. The standard specifies the interface between rolling stock and electrical fixed installations for traction, in the frame ”supply system“. The interaction between pantograph and overhead line is dealt with in EN 50367. The interaction with subsystem “control-command” (especially signalling) is not dealt with in the standard. Requirements are given for the following categories of line: - TSI lines (high speed and conventional), - classical lines. For classical lines, values, if any, are given for the existing European networks. A set of values is also specified for the future network, which is named ”target“ network. The following electric traction systems are concerned: - railways; - guided mass transport systems that are integrated with the railways; - material transport systems that are integrated with the railways. This standard does not apply retrospectively to rolling stock already accepted by infrastructure managers. However, on new infrastructure, existing rolling stock may be accepted by the infrastructure manager, provided there is an agreement. Information is given to the train operating companies on electrification parameters to enable them to confirm after consultation with the rolling stock manufacturers that there will be no consequential disturbance on the electrification system.

EN 50388:2005 is classified under the following ICS (International Classification for Standards) categories: 29.280 - Electric traction equipment; 45.060.01 - Railway rolling stock in general. The ICS classification helps identify the subject area and facilitates finding related standards.

EN 50388:2005 has the following relationships with other standards: It is inter standard links to EN 50388:2012, prEN 50388. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.

EN 50388:2005 is associated with the following European legislation: EU Directives/Regulations: 2008/57/EC, 96/48/EC; Standardization Mandates: M/024. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.

EN 50388:2005 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
