4 Performance characteristics for residential ventilation components/products 4.1 General The results of product performance tests reflect the performance which is achieved by the product in service. A product shall therefore be tested as a complete assembly with all necessary components which affect performance. Accessories are sometimes available for a product as an option. Where accessories could affect performance, the product shall be tested both with and without those accessories. If any insect screen, filter or similar device is intended to be fitted in the product, then it shall be in position when the product is tested. 4.2 Externally mounted air transfer devices 4.2.1 Aerodynamic characteristics The aerodynamic characteristics (pressure/flow rate curve), shall be measured and stated in accordance with EN 13141-1 and EN 13141-9. 4.2.2 Equivalent area The equivalent area shall be calculated and stated in accordance with EN 13141-1 and EN 13141-9. 4.2.3 Free area The free area shall be calculated according to EN 13141-1 and EN 13141-9 with the product in the fully open position and installed according to the manufacturer's instruction. 4.2.4 Controls The manufacturer shall state which type of control is incorporated; e.g. manual control or automatic control according to pressure difference. For manual control the pressure/flow rate curve, equivalent area and free area when fully closed shall be stated under the same test conditions as for the fully open results. If the device is not closable then this shall be stated. NOTE Automatic control by humidity, occupancy or other stimuli is possible, but there is no agreed test method for products with these types of control. 4.2.5 Air diffusion These characteristics shall be measured and the results presented in accordance with EN 13141-1 and EN 13141-9. SIST EN 13142:2013

where
EEw
is the weighted energy efficiency;
vrefq
is the reference air volume flow, in m3.s-1;
refûp is the total reference pressure, in Pa;
ix
is the value of part load of reference air volume flow; iF
is the value of occurrence frequency for part load weighting;
iP
is the electrical power measured at qvi = xi × qvref, in W.  Weighted specific power input calculated according to the formula below with the parameters defined and measured according to EN 13141-4: ∑×=iiivrefW1
xPFqSPI where
SPIw is the weighted specific power input part load;
vrefq
is the reference air volume flow, in m3.s-1;
ix is the value of part load of reference air volume flow; iF is the value of occurrence frequency for part load weighting; iP is the electrical power measured at qvi = xi × qvref, in W. 4.7 Cowls and roof outlet terminals 4.7.1 Pressure drop Pressure drop characteristic shall be measured and the results presented in accordance with EN 13141-5. 4.7.2 Free area The free area of the device shall be determined and the results presented in accordance with EN 13141-5. 4.7.3 Suction effect Suction effect characteristic shall be measured and the results presented in accordance with EN 13141-5. 4.7.4 Acoustic characteristics Fan assisted cowl shall be tested as fan (see 4.6) when the fan is running and as cowl when the fan is not running. SIST EN 13142:2013

Table 4 — Leakage classification – Chamber tracer gas method EN 13141-7 Class a Total recirculated fraction in supply air Rs,tot % B1 ≤ 1 B2 ≤ 2 B3 ≤ 6 Not classified > 6 a Only one class is applicable.
% C1 ≤ 0,5 and ≤ 2 C2 ≤ 2 and ≤ 2 C3 ≤ 4 and ≤ 2 Not classified > 4 or > 2 a Only one class is applicable.
Where tests with different methods on a single unit result in different classes, the product shall receive the higher/worst classification. According to this, the unit has only one of the alternative leakage classes. The tests for air flow/pressure curve and thermal performances shall not be made if the unit is not classified because of measurement uncertainty. 4.9.3.3 Classification of Mass Flow Balance During test procedures according to EN 13141-7, the balance of the units (MFB) shall be measured and the disbalance shall be calculated using the following formula and classified according to Table 6. Disbalance: %100m22m11m22×−=qqqDIS where
DIS
is the disbalance of the unit, in %;
mq
is the mass air flow rate for supply air (22) or extract air (11), in kg.s-1. SIST EN 13142:2013

% Balanced 1 ± 3 Unbalanced Systems 2 ± 6 3 ± 10 4 ± 20 5 ± 30 6 ± 50 Not classified > 50 a Only one option is possible.
4.9.4 Thermal characteristics 4.9.4.1 General The thermal characteristics (including temperature ratios, cold climate performances) shall be measured and the results presented according to EN 13141-7. 4.9.4.2 Classification of Temperature Ratio The Temperature Ratio on Supply air side (TRS) shall be classified. The classification of Temperature Ratio on the Exhaust air side (TRE) is optional. The value of temperature ratios shall be documented at reference air volume flow according to EN 13141-7 and the classification determined according to Table 7. Table 7 — Classification of temperature ratio at reference air volume flow Type Class Temperature Ratio
% TRS - Supply air Side TRE - Exhaust air side 1 ≥ 90 2 80 - 89 3 70 - 79 4 60 - 69 5 50 - 59 Not classified < 50
4.9.4.3 Classification of humidity ratio The humidity ratio shall be classified only if humidity recovery occurs. SIST EN 13142:2013

% HRS - Supply air Side HRE - Exhaust air side I ≥ 90 II 80 - 89 III 70 - 79 IV 60 - 69 V 50 - 59 Not classified < 50
4.9.5 Energy 4.9.5.1 Specific Power Input and classification The Specific Power Input shall be measured and reported according to EN 13141-7. The Specific Power Input (SPI) for units suited for moderate climates includes electrical demand for fans and controls (including remote control and heat pump if installed, not including defrosting, pre-heating and after-heating). SPI is calculated at nominal air volume flow (also named reference air volume flow) at mandatory air measurement point 1 from PE.(EN 13141-7) using the following formulae. averageSUv,EqPSPI= where
SPI
is the specific power input, in W/(m3.s-1);
EP
is the effective power input, in W;
averageSUv,q is the average volume flow rate on supply air side, in m3.s-1. ()2vn22vn11averageSUv,qqq+= where
averageSUv,q is the average volume flow rate on supply air side, in m3.s-1;
vnq
is the nominal air volume flow for supply air (22) or extract air (11), in m3.s-1. SPI shall be classified according to Table 9. SIST EN 13142:2013

W/(m3.s-1) W/(m3/h) 1 ≤ 900 ≤ 0,25 2 ≤ 1 260 ≤ 0,35 3 ≤ 1 620 ≤ 0,45 4 ≤ 1 980 ≤ 0,55 5 ≤ 2 340 ≤ 0,65 6 ≤ 2 700 ≤ 0,75 Not classified > 2 700 > 0,75 a Only one option is applicable.
4.9.5.2 Electrical Power in Operable Mode and classification The Power input in Operable Mode (POM) shall be classified according to Table 10. Operable mode means a mode in which the fans are not operating and controls components are still active (necessary for function of the unit internal or external) according to EN 13141-7:2010, 6.5. Table 10 — Classification of power in operable mode (POM) Class a Power in operable mode
W 1 ≤ 2 2 ≤ 5 3 ≤ 10 4 ≤ 15 Not classified > 15 a Only one option is applicable.
4.9.5.3 Electrical Power in Standby Mode and classification The Power input in Standby Mode (PSM) shall be classified according to Table 11. Standby Mode means a mode manually swit
...
