EN 1364-4:2007

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Preskusi požarne odpornosti nenosilnih elementov - 4. del: Obešene fasade - Delna fasadaFeuerwiderstandsprüfungen für nichttragende Bauteile - Teil 4: Vorhangfassaden - TeilausführungEssais de résistance au feu des éléments non-porteurs - Partie 4: Façades rideaux - Configuration partielleFire resistance tests for non-loadbearing elements - Part 4: Curtain walling - Part configuration91.060.10Stene. Predelne stene. FasadeWalls. Partitions. Facades13.220.50Požarna odpornost gradbenih materialov in elementovFire-resistance of building materials and elementsICS:Ta slovenski standard je istoveten z:EN 1364-4:2007SIST EN 1364-4:2007en,fr,de01-september-2007SIST EN 1364-4:2007SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1364-4March 2007ICS 13.220.50 English VersionFire resistance tests for non-loadbearing elements - Part 4:Curtain walling - Part configurationEssais de résistance au feu des éléments non-porteurs -Partie 4: Façades rideaux - Configuration partielleFeuerwiderstandsprüfungen für nichttragende Bauteile -Teil 4: Vorhangfassaden - TeilausführungThis European Standard was approved by CEN on 9 December 2006.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2007 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1364-4:2007: ESIST EN 1364-4:2007

Guidance on testing curtain walling – part configuration.20 A.1 Standard configuration.20 A.1.1 General.20 A.1.2 Supporting floor.20 A.1.3 Parts of curtain walling system.20 A.1.4 Specimen selection.20 A.2 Test principles and requirements.21 A.3 Fire from the inside.24 A.3.1 General.24 A.3.2 Non-fire-resistant glazing.24 A.3.3 Fire-resistant glazing.25 A.4 Fire from the outside.25 Annex B (normative)
Standard configurations.28 B.1 General.28 B.2 Description of the standard configurations.29 Bibliography.42
WARNING
The attention of all persons concerned with managing and carrying out this fire resistance test is drawn to the fact that fire testing can be hazardous and that there is a possibility that toxic and/or harmful smoke and gases can be developed during the test. Mechanical and operational hazards can also arise during the construction of the test elements or structures, their testing and disposal of test residues. An assessment of all potential hazards and risks to health should be made and safety precautions should be identified and provided. Written safety instructions should be issued. Appropriate training should be given to relevant personnel. Laboratory personnel should ensure that they follow written safety instructions at all times.
NOTE see Figure A.2 3.13 upstand special type of spandrel panel, standing up from or located in front of the floor
NOTE see Figure A.2 3.14 over-cladding system weather protection system applied to an external wall, sometimes referred to as rain screen 3.15 external fire exposure curve alternative heating regime used to simulate the exposure of a wall to a fire from the outside 3.16 standard configuration arrangement of curtain wall components in a test specimen with standard features to enable the use of extended application rules of test data
NOTE see Annex A 3.17 supporting floor representation of a floor, forming part of the test equipment, to allow the fixing of the test specimen of the curtain wall and the installation of the horizontal linear gap seal
NOTE see Annex B 3.18 mechanical stability ability to resist a part of a curtain walling dropping from the specimen as a result of a fixing failure NOTE This corresponds to the wording of Mandate 117 “falling parts”. 4 Test equipment 4.1 General testing principles Table 1 defines which specific test configuration shall be used for each part of the curtain walling depending on the type of fire exposure. The test equipment specified in EN 1363-1 and EN 1363-2 shall be used where applicable. SIST EN 1364-4:2007

EN 1363-2 2
Fire-resistant glazing EN 1363-1 3
EN 1363-2 4 Downstand Non-fire-resistant glazing EN 1363-1 5
EN 1363-2 6
Fire-resistant glazing EN 1363-1 7
EN 1363-2 8 Upstand
Non-fire-resistant glazing EN 1363-1 9
EN 1363-2 10
Fire-resistant glazing EN 1363-1 11
EN 1363-2 12 Horizontal linear gap seal Non-fire-resistant glazing EN 1363-1 1, 5, 9, 13
Fire-resistant glazing EN 1363-1 3, 7, 11, 14 Fixing Non-fire-resistant glazing EN 1363-1 15
Fire-resistant glazing EN 1363-1 16 NOTE For more information on the test configuration depending on the heating exposure and explanation, see Table A.1.
4.2 Furnace configuration For the installation of the specimen, wall or floor furnaces shall be modified, if necessary, to accommodate the three-dimensional construction. The three dimensional construction includes the horizontal linear gap seal. The test according to EN 1364-4 is performed on a three-dimensional specimen to allow an exposure of a number of surfaces of the upstand/downstand (spandrel area) and incorporates a standard floor, which provides the support for the curtain wall. The lining of the furnace closure shall comply with EN 1363-1 or may consist of aerated autoclaved concrete with a density of 400 to 550 kg/m3. 4.3 Supporting floor A supporting floor is provided as a base for the attachment of the fixings and as a location for the horizontal linear gap seal under examination. If information on the fire resistance of the curtain walling in conjunction with a particular type of floor construction is required, such a construction shall be used, see 7.2. SIST EN 1364-4:2007

Supporting floor Upstand / downstand / combination Horizontal linear gap seal 1 Simplified example of fixing S1 Surface 1 S2 Surface 2 S3 Surface 3 S5 Surface 5 Figure 1 — Definition of surfaces
6.5 Design 6.5.1 General The test specimen shall be:  either fully representative of the construction intended for use in practice, including fixings, expansion joints, horizontal linear gap seals, any surface finishes and fittings which are essential and may influence its behaviour in the test,  or be designed to obtain the widest applicability of the test result to other similar constructions. For standard configurations see Annex B. All design features which influence fire performance shall be included. Where the width of a single spandrel panel (upstand/downstand) is less than 3 m, at least 3 panels with the mid panel at the maximum dimension shall be incorporated in the test specimen. Where the width of the panel is greater than or equal to 3 m, at least 3 panels with the mid panel at the maximum dimension and the side panels at least 50 cm wide shall be incorporated in the test specimen. SIST EN 1364-4:2007

1VXVYS3VYVXS3S53D3E3B3A3F3CAA - A Key
Supporting floor Upstand / downstand / combination Furnace wall 3A to 3F Location of thermocouples 3A to 3F VX, VY Location of thermocouples VX and VY 1 Horizontal linear gap seal S3, S5 Surfaces 3, 5 A-A Vertical section Figure 2 — Location of thermocouples on Surface S3 for internal exposure and external exposure – View from inside the furnace 9.2.3.2 Horizontal linear gap seal For the determination of the maximum temperature rise, thermocouples shall be applied to the horizontal linear gap seal as follows (see Figure 3):  Thermocouple HV: at the top surface of the seal, centrally between the mullions and centrally across the horizontal linear gap seal,  Thermocouple HW: at the top surface of th
...
