DRAFT International Standard ISO/DIS 19085-15:2026(en)
Woodworking machines — Safety —
Part 15:
Presses
1 Scope
This document specifies the safety requirements and measures for
— cold presses,
— hot presses,
— bending presses,
— edge/face gluing presses,
— membrane presses, and
— embossing presses,
where the pressing force is applied by hydraulic, pneumatic or electrical actuators pushing two flat or shaped
surfaces against each other, capable of continuous production use, altogether referred to as “machines”.
This document deals with all significant hazards, hazardous situations and events as listed in Annex A,
relevant to machines, when used as intended and under conditions of misuse which are reasonably
foreseeable, as well as when it is transported, assembled, adjusted, maintained, disabled, dismantled and
scrapped.
The machines are designed to process workpieces consisting of:
— solid wood;
— materials with similar characteristics to wood (see ISO DIS 19085-1:2025, 3.2), except those with light
alloy laminates or edges or profiles for high-frequency presses;
— engineered wood (wood-based material) such as particleboard, fibreboard and plywood composed or
laminated with steel sheets or edges or profiles, except for high-frequency presses;
— honeycomb board;
— composite boards made from the materials listed above.
This document is applicable to machines fitted with one or more of the following devices or additional
working units, whose hazards have been dealt with:
a) a device for hot gluing;
b) a device for high-frequency gluing in the frequency range from 1 MHz to 400 MHz;
c) a device for high-frequency shaping in the frequency range from 1 MHz to 400 MHz;
d) an automatic workpiece loading and unloading system;
e) an intermediate additional platen;
f) a workpiece extractor;
ISO/DIS 19085-15:2026(en)
g) a horizontal pressing system;
h) split moveable platens.
This document does not deal with any hazards related to:
— specific devices that differ from the list above;
— hot fluid heating systems internal to the machine other than electrical;
— hot fluid heating systems of any type external to the machine;
— operation of taking intermediate platens out and in again;
— the combination of a single machine being used with any other machine (as part of a line).
This document is not applicable to:
— carcass clamps;
— membrane presses where the pressing force is applied by vacuum only;
— presses for producing particleboard, fibreboard, OSB;
— machines intended for use in potentially explosive atmosphere;
— machines manufactured before the date of publication of this document.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
ISO 7010:2019, Graphical symbols — Safety colours and safety signs — Registered safety signs
ISO 7010:2019/Amd 1:2020, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 1
ISO 7010:2019/Amd 2:2020, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 2
ISO 7010:2019/Amd 3:2021, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 3
ISO 7010:2019/Amd 4:2021, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 4
ISO 7010:2019/Amd 5:2022, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 5
ISO 7010:2019/Amd 6:2022, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 6
ISO 7010:2019/Amd 7:2023, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 7
ISO 7010:2019/Amd 8:2024, Graphical symbols — Safety colours and safety signs — Registered safety signs —
Amendment 8
ISO 12100:2010, Safety of machinery — General principles for design — Risk assessment and risk reduction
ISO 13850:2015, Safety of machinery — Emergency stop function — Principles for design

ISO/DIS 19085-15:2026(en)
ISO 13855:2024, Safety of machinery — Positioning of safeguards with respect to the approach of the human
body
ISO/DIS 19085-1:2025, Woodworking machines — Safety — Part 1: Common requirements
IEC 60204-1:2016, Safety of machinery — Electrical equipment of machines — Part 1: General requirements
IEC 61310-1:2007, Safety of machinery — Indication, marking and actuation — Part 1: Requirements for visual,
acoustic and tactile signals
IEC 62311:2019, Assessment of electronic and electrical equipment related to human exposure restrictions for
electromagnetic fields (0 Hz to 300 GHz)
E N 12198 -1:2000 +A 1: 2008 , Safety of machinery — Assessment and reduction of risks arising from radiation
emitted by machinery — Part 1: General principles
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 12100:2010, ISO 13849-1:2023,
ISO DIS 19085-1:2025 and the following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
cold press
machine used to laminate or join together flat panels, or both, in which the pressing force is applied by
hydraulic, pneumatic or electrical actuators pushing two cold flat platens against each other
Note 1 to entry: The moveable platen can be the top or the bottom one or both. Examples of different machine designs
are illustrated in Figures 1 and 2 (safeguarding devices are not fully illustrated).
Note 2 to entry: The following devices can be provided:
— automatic panel loading and unloading;
— split moveable platens (see Figure 14).
3.2
hot press
machine used to laminate or join together flat panels, or both, in which the pressing force is applied by
hydraulic actuators pushing two hot flat platens against each other
Note 1 to entry: The moveable platen can be the top or the bottom one or both. Examples of different machine designs
are illustrated in Figures 1 and 2 (safeguarding devices are not fully illustrated).
Note 2 to entry: The following devices can be provided:
— automatic panel loading and unloading;
— intermediate additional platens (see Figure 3).
Note 3 to entry: Platens heating systems can be by electrical resistance or hot fluid (e.g. diathermic oil, water). Fluid
heating system can be internal to the machine or external.

ISO/DIS 19085-15:2026(en)
Figure 1 — Example of a cold or hot press with bottom actuators
Figure 2 — Example of a cold or hot press with top actuators

ISO/DIS 19085-15:2026(en)
Figure 3 — Example of a hot press with intermediate platens
3.3
bending press
machine with manual loading or unloading or both used to assembly or shape flat panels, or both, in which
the pressing force is applied by hydraulic actuators pushing two shaped surfaces against each other, and the
hot gluing process is by hot dies or high-frequency system
Note 1 to entry: For an example, see Figure 4 (safeguarding devices are not fully illustrated).

ISO/DIS 19085-15:2026(en)
Figure 4 — Example of a bending press with top actuators
3.4
edge/face gluing press
machine used to join together solid wood bars, in which the pressing force is applied by hydraulic, pneumatic
or electrical actuators vertically pushing two flat platens against each other, and horizontally pushing
elements against each other, and the gluing process is by hot platens or high-frequency system or as a cold
press with adequate adhesives
Note 1 to entry: The following devices can be provided:
— workpieces extractor;
— automatic panel loading and unloading system;
— horizontal pressing system (3.15).
Note 2 to entry: For an example, see Figure 5 (safeguarding devices are not fully illustrated).

ISO/DIS 19085-15:2026(en)
a) “Bridge” type b) “Cantilever” type
Figure 5 — Example of an edge/face gluing press
3.5
membrane press
machine used to laminate or veneer flat or shaped workpieces, in which the pressing force is applied
through a membrane pushed onto the workpiece by compressed air from above and by vacuum from below,
hermetically enclosed by two shells, of which the upper one is heated, pushed against each other by hydraulic
actuators
Note 1 to entry: Automatic panel loading and unloading devices can be provided.
Note 2 to entry: Upper shell heating systems can be by electrical resistance or hot fluid (e.g. diathermic oil, water).
Fluid heating system can be internal to the machine or external.
Note 3 to entry: For an example, see Figure 6 (safeguarding devices are not fully illustrated).

ISO/DIS 19085-15:2026(en)
Figure 6 — Example of a membrane press
3.6
embossing press
machine used to emboss workpieces by a special mould or die fixed to the upper plate, in which the pressing
force is applied by hydraulic actuators pushing two hot flat platens against each other
Note 1 to entry: The moveable platen can be the top or the bottom one or both. Examples of different machine designs
are illustrated in Figures 1 and 2 (safeguarding devices are not fully illustrated).
Note 2 to entry: Automatic panel loading and unloading devices can be provided.
Note 3 to entry: Platens heating systems can be by electrical resistance or hot fluid (e.g. diathermic oil, water). Fluid
heating system can be internal to the machine or external.
3.7
daylight
compartment between two consecutive pressing platens
3.8
automatic workpiece loading/unloading system
system for automatic dragging workpieces into or out of the machine, whereby the workpiece is manually
loaded onto or unloaded from the system itself
Note 1 to entry: Six usual types of automatic workpiece loading/unloading systems are considered in this document.
3.9
automatic workpiece loading/unloading system type 1
system consisting of an automatic belt or chain or roller conveyor for loading workpieces into the daylight
(3.7), a feeding belt or chain or roller device applied to the bottom platen and idle roller conveyor or an
automatic belt or chain or roller conveyor for unloading workpieces
Note 1 to entry: For an example, see Figure 7 (safeguarding devices are not fully illustrated).

ISO/DIS 19085-15:2026(en)
Key
1 automatic belt conveyor for loading
2 feeding belt device applied to the bottom platen
3 idle roller conveyor for unloading
4 feed direction
Figure 7 — Example of an automatic workpiece loading/unloading system type 1
3.10
automatic workpiece loading/unloading system type 2
system similar to automatic workpiece loading/unloading system type 1 (3.9) but with an automatic hybrid
chain and belt feeding device applied to the platens
Note 1 to entry: For an example, see Figure 8 (safeguarding devices are not fully illustrated).
Key
1 hybrid chain and belt feeding device
2 feed direction
3 shaft for feeding belt tensioning
Figure 8 — Example of a hybrid chain and belt device

ISO/DIS 19085-15:2026(en)
3.11
automatic workpiece loading/unloading system type 3
system consisting of an automatic pusher for loading workpieces into the daylight (3.7)
Note 1 to entry: Loading a workpiece into the daylight pushes out the previous workpiece.
Note 2 to entry: Unloading support can be either inclined idle roller conveyor or horizontal table.
Note 3 to entry: See Figure 9 for an example with an unloading inclined idle roller conveyor (safeguarding devices are
not fully illustrated).
Key
1 automatic pusher
2 feed direction
3 platens
Figure 9 — Example of an automatic workpiece loading/unloading system type 3
3.12
automatic workpiece loading/unloading system type 4
system consisting of an automatic sliding belt conveyor for loading workpieces into the daylight (3.7) and for
unloading workpieces onto a roller conveyor
Note 1 to entry: When the sliding belt conveyor loads a workpiece into the daylight, at the same time it pushes out any
workpiece previously in the daylight.
Note 2 to entry: For an example, see Figure 10.

ISO/DIS 19085-15:2026(en)
Key
1 sliding belt conveyor
2 loaded workpiece
3 unloaded workpiece
4 platens
5 unloading roller conveyor
Figure 10 — Example of an automatic workpiece loading/unloading system type 4
3.13
automatic workpiece loading/unloading system type 5
system consisting of an automatic sliding belt conveyor for loading workpieces in the daylight (3.7) in
combination with a vacuum system for unloading workpieces onto a roller conveyor
Note 1 to entry: For an example, see Figure 11.
Key
1 sliding belt conveyor
2 loaded workpiece
3 unloaded workpiece
4 platens
5 vacuum system for unloading
6 unloading roller conveyor
Figure 11 — Example of an automatic workpiece loading/unloading system type 5

ISO/DIS 19085-15:2026(en)
3.14
automatic workpiece loading/unloading system type 6
system consisting of an automatic belt or roller multi-conveyor for loading workpieces in a multi-daylight
machine, a feeding belt or chain or roller device applied to the platens and an automatic belt or roller multi-
conveyor for unloading workpieces
Note 1 to entry: Each single conveyor of the multi-conveyor (see Figure 12 Keys 2 and 5) can move up and down in
order to align with daylights (3.7).
Note 2 to entry: Multi-conveyors are loaded/unloaded by single automatic belt or roller conveyors.
Note 3 to entry: For an example, see Figure 12 (safeguarding devices are not fully illustrated).
Key
1 single load belt conveyor
2 automatic belt multi-conveyor for loading
3 multi-daylight machine
4 feeding belt devices applied to the platens
5 automatic belt multi-conveyor for unloading
6 roller conveyor for unloading
7 feed direction
Figure 12 — Example of an automatic workpiece loading/unloading system type 6
3.15
horizontal pressing system
system consisting of horizontal pressing elements, together with a beam and a platen that clamp the
workpieces in position from above before the horizontal pressing elements close
Note 1 to entry: For an example, see Figure 13.

ISO/DIS 19085-15:2026(en)
Figure 13 — Examples of horizontal pressing system
3.16
split movable platen
platen, covering the whole working area, divided into sections that move independently, to process smaller
workpieces of different heights at the same time
Note 1 to entry: The split platen can be top or bottom.
Note 2 to entry: For an example, see Figure 14 (safeguarding devices are not fully illustrated).
Figure 14 — Example of a cold press with split moveable platen
3.17
jog
control device for momentary activation of a function or a movement

ISO/DIS 19085-15:2026(en)
4 Safety requirements and measures for controls
4.1 Safety and reliability of control systems
ISO DIS 19085-1:2025, 4.1, shall apply.
Annex B, Table B.1 summarizes the performance levels required (PL ) in Clauses 4 and 5 for all safety
r
functions.
4.2 Control devices
4.2.1 General
ISO DIS 19085-1:2025, 4.2.1, shall apply.
The main electrical control devices of the machine for control power-on, jog, normal stop, two-hand control
and integrated fee
...
