(Main)Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy - Port connection
Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy - Port connection
This standard specifies the characteristics of port connection for pipe couplings, 60°, spherical, in titanium alloy, for aerospace applications.
It is applicable to 60°Ispherical tube coupling in titanium alloy defined by the EN 3853 standard, to be mounted with O-ring defined in accordance with the TR 4052.
Luft- und Raumfahrt - Rohrverschraubungen mit Kugelbuchsen, 60°, aus Titanlegierung - Einschraublöcher
Diese Norm legt die Eigenschaften von Einschraublöchern für Rohrverschraubungen 60° mit Kugelbuchse, aus Titanlegierung, für Anwendungen in der Luft- und Raumfahrt fest.
Sie ist in Verbindung mit der Rohrverschraubung 60° mit Kugelbuchse aus Titanlegierung nach EN 3853 anzuwenden, die mit dem in TR 4052 festgelegten O-Ring zu montieren ist.
Série aérospatiale - Raccords, sphériques, 60°, en alliage de titane - Logement d'implantation
Aerospace series - Pipe couplings, 60°, spherical, in titanium alloy - Port connection
