INTERNATIONAL STANDARD ISO 4377:2012(E)

Hydrometric determinations — Flow measurement in open
channels using structures — Flat-V weirs
1 Scope
This International Standard describes the methods of measurement of flow in rivers and artificial channels
under steady or slowly varying conditions using flat-V weirs (see Figure 1).
Annex A gives guidance on acceptable velocity distribution.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies
ISO 772, Hydrometry — Vocabulary and symbols
ISO/TS 25377, Hydrometric uncertainty guidance (HUG)

1:5
> H > 2H
1max. 1max.
-
-
> H
1max.
-
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 772 apply.
Dimensions in millimetres
R > 2H
- 1max.
10 H' but not ≤ 3H
1max.
h
25 H' but not ≤ 3H
1max.
p
1:2
1 7
p
Key
1 head gauging section b crest width
2 upstream tapping H' difference between the invert (apex) of the V and the
top of the V
H
3 stilling wells maximum upstream total head above crest elevation
1max
4 crest tapping h gauged head above lowest crest elevation
5 flow p difference between mean bed level and lowest crest
elevation
6 downstream head measuring point
7 minimum 100 mm above stilling basin level
8 limits of permissible upstream and downstream
truncations
Figure 1 — Triangular profile flat-V weir

2 © ISO 2012 – All rights reserved

0,1 b
0,4 b
b
m
4 Symbols
The following is a list of symbols used, with the corresponding units of measurement.
a
Meaning Units
Symbol
A Area of cross-section of flow m
B Width of approach channel m
b Crest width m
C Coefficient of discharge Non-dimensional
D
C Effective coefficient of discharge Non-dimensional
De
C Drowned flow reduction factor Non-dimensional
dr
C Coefficient of approach velocity Non-dimensional

2
g Gravitational acceleration (standard value) ms
H Total head above lowest crest elevation m
H Total effective upstream head m
1e
H Total effective downstream head m
2e
H Maximum upstream total head above crest elevation m
1max
h Gauged head above lowest crest elevation m
h Upstream gauged head m
h Effective upstream gauged head m
1e
h Downstream gauged head m
h Effective downstream gauged head m
2e
h Separation pocket head m
p
h Effective separation pocket head relative to lowest crest elevation m
pe
h′, H′ Difference between lowest and highest crest elevations m
K ,K Constants Non-dimensional
1 2
k Head correction factor m
h
L Distance of upstream head measurement position from crest line m
m Crest cross-slope (1 vertical: m horizontal) Non-dimensional
n Number of measurements in a set Non-dimensional
p Difference between mean bed level and lowest crest elevation m
3 1
Q Discharge m s
3 1
Q Total daily flow volume m d
dfv
t Measurement observation frequency time minutes
v Mean velocity at cross-section m/s
 Mean velocity in approach channel m/s
a
u Absolute uncertainty in head measurement m
h
u(E) Absolute uncertainty in gauge zero m
*
u ( Percentage uncertainty in discharge coefficient Non-dimensional
CD)
*
u (C ) Percentage uncertainty in coefficient of velocity Non-dimensional

*
u (C ) Percentage uncertainty in drowned flow reduction factor Non-dimensional
dr
*
u (h) Percentage uncertainty in head measurement Non-dimensional

*
u (H ) Percentage uncertainty in total effective head Non-dimensional
e
*
U (Q) Percentage uncertainty in discharge determination Non-dimensional
*
U (Q ) Percentage uncertainty in the daily mean flow Non-dimensional
dmf
*
U (Q ) Percentage uncertainty in the total daily flow volume Non-dimensional
dfv
Z , Z Shape factors Non-dimensional
h H
α Coriolis energy coefficient Non-dimensional
Subscript
1 denotes upstream value
2 denotes downstream value
e denotes “effective” and implies that corrections for fluid effects
have been made to the quantity
a denotes approach channel
5 Characteristics of flat-V weirs
The standard flat-V weir is a control structure, the crest of which takes the form of a shallow V when viewed in
the direction of flow.
The s
...
