DRAFT INTERNATIONAL STANDARD ISO/DIS 17987-4.2

1 Road vehicles — Local Interconnect Network (LIN) — Part 4:
2 Electrical Physical Layer (EPL) specification 12V/24V
3 1 Scope
4 This part of ISO 17987 specifies the 12 V and 24 V electrical physical layers (EPL) of the LIN communications
5 system.
6 The electrical physical layer for LIN is designed for low cost networks with bit rates up to 20 kbit/s to connect
7 automotive electronic control units (ECUs). The medium that is used is a single wire for each, receiver and
8 transmitter with reference to ground.
9 This part of ISO 17987 includes the definition of electrical characteristics of the transmission itself and also
10 documentation of basic functionality for bus driver devices.
11 All parameters in this specification are defined for the ambient temperature range from -40°C to 125°C.
12 2 Normative references
13 The following referenced documents are indispensable for the application of this document. For dated
14 references, only the edition cited applies. For undated references, the latest edition of the referenced
15 document (including any amendments) applies.
16 ISO 17987 (Part 2, 3, 6 and 7), Road vehicles – Local interconnect network (LIN)
17 3 Terms, definitions, symbols and abbreviated terms
18 3.1 Terms and definitions
19 For the purposes of this document, the following terms and definitions apply.
20 3.1.1
21 BR_Range_20K
22 LIN systems which operate at speeds up to 20 kbit/s
23 3.1.2
24 BR_Range_20K 12 V
25 12 V LIN systems which operate at speeds up to 20 kbit/s
26 3.1.3
27 BR_Range_20K 24 V
28 24 V LIN systems which operate at speeds up to 20 kbit/s
29 3.1.4
30 BR_Range_10K
31 LIN systems which operate at speeds up to 10,417 kbits/s
ISO/DIS 17987-4.2
32 3.1.5
33 BR_Range_10K 12 V
34 12 V LIN systems which operate at speeds up to 10,417 kbits/s
35 3.1.6
36 BR_Range_10K 24 V
37 24 V LIN systems which operate at speeds up to 10,417 kbit/s
38 3.2 Symbols
% percentage
µs microsecond
C' line capacitance
LINE
C total bus capacitance
BUS
C capacitance of master node
MASTER
C RXD capacitance (LIN receiver, RXD capacitive load condition)
RXD
C capacitance of slave node
SLAVE
d²V/dt² second derivative of voltage (Volt² per second²)
di/dt instantaneous rate of current change (amps per second)
D serial internal diode at transceiver IC
ser_int
D serial master diode
ser_master
F master bit rate deviation from nominal bitrate
TOL_RES_MASTER
F master bit rate deviation from nominal bitrate in BR_Range_20K systems
TOL_RES_MASTER_A
F master bit rate deviation from nominal bitrate in BR_Range_10K systems
TOL_RES_MASTER_B
F slave bit rate deviation from nominal bitrate
TOL_RES_SLAVE
F slave bit rate deviation from nominal bitrate in BR_Range_20K systems
TOL_RES_SLAVE_A
F slave bit rate deviation from nominal bitrate in BR_Range_10K systems
TOL_RES_SLAVE_B
F slave node 1 bit rate deviation from nominal bitrate
TOL_RES_SLAVE_1
F slave node 2 bit rate deviation from nominal bitrate
TOL_RES_SLAVE_2
F slave to slave bit rate deviation
TOL_SLAVE_to_SLAVE
F slave node bit rate deviation from master node bit rate after synchronization
TOL_SYNCH
F slave node bit rate deviation from master node bit rate after synchronization in
TOL_SYNCH_A
BR_Range_20K systems
F slave node bit rate deviation from master node bit rate after synchronization in
TOL_SYNCH_B
BR_Range_10K systems
2 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
F slave node 1 bit rate deviation from master node bit rate after synchronization
TOL_SYNCH_1
F slave node 2 bit rate deviation from master node bit rate after synchronization
TOL_SYNCH_2
F slave node bit rate deviation from nominal bit rate before synchronization
TOL_UNSYNCH
F slave node bit rate deviation from nominal bit rate before synchronization in
TOL_UNSYNCH_A
BR_Range_20K systems
F slave node bit rate deviation from nominal bit rate before synchronization in
TOL_UNSYNCH_B
BR_Range_10K systems
I current into the ECU bus line
BUS
I current limitation for driver dominant state driver on V = V into ECU bus line
BUS_LIM BUS BAT_max
I current at ECU bus line when V is disconnected
BUS_NO_BAT BAT
I current at ECU bus line when V is disconnected
BUS_NO_GND GND_ECU
I current at ECU bus line when driver off (passive) at dominant LIN bus level
BUS_PAS_dom
I current at ECU bus line when driver off (passive) at recessive LIN bus level
BUS_PAS_rec
GND GND of ECU
Device
KΩ kilo ohm
kbit/s kilo bit per second
LEN total length of LIN bus line
BUS
LIN LIN network
Bus
ms millisecond
nF nano farad
pF pico farad
pF/m pico farad per meter (line capacitance)
R total bus-resistor including all slave and master resistors
BUS
R = R || R || R || to || R
BUS MASTER SLAVE_1 SLAVE_2 SLAVE_N
R master resistor
MASTER
R pull-up resistor
pull_up
R slave resistor
SLAVE
t byte field synchronization time
BFS
t basic bit times
BIT
t earliest bit sample time
EBS
t propagation delay of receiver
rx_pd
ISO/DIS 17987-4.2
t symmetry of receiver propagation delay rsising edgepropagation delay of receiver
rx_sym
t latest bit sample time
LBS
t propagation delay time of receiving node 1 at falling (recessive to dominant ) LIN bus
rx_pdf(1)
edge
t propagation delay time of receiving node 2 at falling (recessive to dominant ) LIN bus
rx_pdf(2)
edge
t propagation delay time of receiving node 1 at rising (dominant to recessive) LIN bus
rx_pdr(1)
edge
t propagation delay time of receiving node 2 at rising (dominant to recessive) LIN bus
rx_pdr(2)
edge
t sample window repetition time
SR
TH max. dominant threshold of receiving node (Volt)
Dom(max)
TH min. dominant threshold of receiving node (Volt)
Dom(min)
TH max. recessive threshold of receiving node (Volt)
Rec(max)
TH min. recessive threshold of receiving node (Volt)
Rec(min)
V voltage
V voltage at the anode of the diode
ANODE
V voltage across the ECU supply connectors
BAT
V voltage across the vehicle battery connectors
BATTERY
V voltage on the LIN bus
BUS
V center point of receiver threshold
BUS_CNT
V receiver recessive voltage
BUS_rec
V voltage at the cathode of the diode
CATHODE
V battery ground voltage
GND_BATTERY
V voltage on the local ECU ground connector with respect to vehicle battery ground
GND_ECU
connector (V )
GND_BATTERY
V receiver hysteresis voltage
HYS
V recessive voltage
Rec
V
SerDiode
voltage drop at the serial diodes
V battery shift
Shift_BAT
V difference between battery shift and GND shift
Shift_Difference
V GND shift
Shift_GND
4 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
V voltage at transceiver supply pins
SUP
V voltage which the device is not destroyed; no guarantee of correct operation
SUP_NON_OP
V receiver threshold voltage of the recessive to dominant LIN bus edge
th_dom
V receiver threshold voltage of the dominant to recessive LIN bus edge
th_rec
ΔF / F deviation of node bit rate from the master node bit rate
MASTER
ΔF / F deviation from nominal bit rate
Nom
τ time constant
Ω ohm
40 3.3 Abbreviated terms
AC alternate current
API application programmers interface
ASIC application specific integrated circuit
BFS byte field synchronization
DC direct current
EBS earliest bit sample
EMC electromagnetic compatibility
EMI electromagnetic interference
EPL electrical physical layer
ESD electrostatic discharge
EVT event
GND ground
LBS latest bit sample
Max maximum
Min minimum
OSI open systems interconnection
RC RC time constant τ (τ = C * R )
BUS BUS
RX Rx pin of the transceiver
RXD receive data
ISO/DIS 17987-4.2
SR sample window repetition
TRX transceiver
Tx Tx pin of the transceiver
TXD transmit data
Typ. typical
UART universal asynchronous receiver transmitter
41 4 Conventions
42 ISO 17987 and ISO 14229-7 [8] are based on the conventions specified in the OSI Service Conventions
43 (ISO/IEC 10731) [2] as they apply for physical layer, protocol, network & transport protocol and diagnostic
44 services.
45 5 Electrical physical layer requirements
46 5.1 Bit rate deviation
47 The bit rate deviation of the LIN medium describes the bit rate deviation from a referenced bit rate. It is the
48 sum of the following parameters:
49  Inaccuracy of setting the bit rate (systematic failure due to granularity of the configurable bit rate)
50  Clock deviation over temperature and supply voltage range
51  Clock source stability of the slave node starting from the end of the sync byte field up to the end of the
52 entire LIN frame (last sampled bit) when performing synchronization.
53  Bit time measurement failure of the slave node
54  Clock source stability of the master node starting from the end of the sync byte field up to the end of the
55 entire LIN frame (last transmitted bit)
56 On-chip clock may achieve a frequency deviation of better than ± 14 % with internal calibration. This bit rate
57 deviation better than ± 14 % is sufficient to detect a break field in the message stream. The subsequent bit
58 rate adaptation using the sync byte field ensures the proper reception and transmission of the message. The
59 on-chip oscillator shall allow for accurate bite rate measurement and generation for the remainder of the
60 message frame, taking into account effects of anything, which affects the bit rate, such as temperature and
61 voltage drift during operation.
62 The bit rates on the LIN bus are specified in the range of 1 to 20 kbit/s. The specific bit rate used on a LIN bus
63 is defined as the nominal bit rate F .
Nom
64 In case a non-LIN electrical physical layer (e.g. ISO 11898-1, ISO 11898-2) is used, the bit rate may have to
65 be adjusted.
66 5.1.1 12 V LIN systems: Parameters
67 Table 1 defines the bit rate deviation from nominal bit rate.
6 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
68 Table 1 — Bit rate deviation from nominal bit rate
Number Bit rate deviation Name ΔF/F .
Nom
Param 1 Master node (deviation from nominal bit rate) F < ± 0,5 %
TOL_RES_MASTER
Param 2 Slave node without making use of synchronization (deviation from F < ± 1,5 %
TOL_RES_SLAVE
nominal bit rate)
Param 3 Deviation of slave node bit rate from the nominal bit rate before F < ± 14 %
TOL_UNSYNCH
synchronization; relevant for nodes making use of synchronization and
direct break detection.
This parameter is microprocessor based nodes with sync/break detection
that is triggering the auto-bauding processing in software. It insures that
the break is detected.
70 Table 2 defines the slave node bit rate deviation from master node bit rate.
71 Table 2 — Slave node bit rate deviation from master node bit rate
Number Bit rate deviation Name ΔF/F
Master
Param 4 Deviation of slave node bit rate from the master node bit rate after F < ± 2 %
TOL_SYNCH
synchronization; relevant for nodes making use of synchronization; any
slave node shall stay within this deviation for all fields of a frame which
follow the sync byte field.
73 Table 3 defines the bit rate deviation for slave to slave communication.
74 Table 3 — Bit rate deviation for slave to slave communication
Number Bit rate deviation Name ΔF/F
Master
Param 5 For communication between any two nodes (i.e. data stream from one F < ± 2 %
TOL_SLAVE_to_SLAVE
slave to another slave) their bit rate shall not differ by more than
F . The following condition shall be checked for:
TOL_SLAVE_to_SLAVE
a) |F - F | < F
TOL_RES_SLAVE_1 TOL_RES_SLAVE_2 TOL_SLAVE_to_SLAVE
b) |F - F | < F
TOL_SYNCH_1 TOL_SYNCH_2 TOL_SLAVE_to_SLAVE
c) |(F + F ) - F |
TOL_RES_MASTER TOL_SYNCH_1 TOL_RES_SLAVE_2
< F
TOL_SLAVE_to_SLAVE
76 5.1.2 24 V LIN systems: Parameters
77 The required accuracy is dependent on the used bitrate range. See Table 15 and also ISO 17987-2.
78 Table 4 defines the bit rate deviation from nominal bitrate in BR_Range_20K systems.
79 Table 4 — Bit rate deviation from nominal bitrate in BR_Range_20K systems
Number BR_Range_20K bit rate deviation Name ΔF / F
Nom.
Param 39 master node
(deviation from nominal bit rate. The nominal bit rate F is defined F < ± 0,3 %
Nom TOL_RES_MASTER_A
in the LIN description file).
ISO/DIS 17987-4.2
Param 40 slave node without making use of synchronization (deviation from
nominal bit rate)
F < ± 0,3 %
TOL_RES_SLAVE_A
For communication between any two nodes their bit rate shall not
differ by more than ± 0,6 %.
Param 41 deviation of slave node bit rate from the nominal bit rate before
synchronization; relevant for nodes making use of synchronization F < ± 14 %
TOL_UNSYNCH_A
and direct break field detection.
81 Table 5 defines the bit rate deviation for slave nodes from master node in BR_Range_20K systems.
82 Table 5 — Bit rate deviation for slave nodes from master node in BR_Range_20K systems
Number BR_Range_20K bit rate deviation Name ΔF / F
MASTER
Param 42 Deviation of slave node bit rate from the master node bit rate after
synchronization; relevant for nodes making use of
F < ± 0,6 %
TOL_SYNCH_A
synchronization; any slave node shall stay within this deviation for
all fields of a frame which follow the sync byte field.
Param 43 For communication between any two nodes (i.e. data stream from
one slave to another slave) their bit rate shall not differ by more
than F . The following condition shall be checked
TOL_SLAVE_to_SLAVE
for:
a) |F - F | < F
TOL_RES_SLAVE_1 TOL_RES_SLAVE_2 TOL_SLAVE_to_SLAVE F < ± 0,6 %
TOL_SLAVE_to_SLAVE
b) |F - F | < F
TOL_SYNCH_1 TOL_SYNCH_2 TOL_SLAVE_to_SLAVE
c) |(F + F ) - F |
TOL_RES_MASTER_A TOL_SYNCH_1 TOL_RES_SLAVE_2
< F
TOL_SLAVE_to_SLAVE
84 Table 6 defines the Bit rate deviation from nominal bitrate in BR_Range_10K systems.
85 Table 6 — Bit rate deviation from nominal bitrate in BR_Range_10K systems
Number BR_Range_10K bit rate deviation Name ΔF / F
Nom
Param 44 master node
(deviation from nominal bit rate. The nominal bit rate F is F < ± 0,5 %
Nom TOL_RES_MASTER_B
defined in the LDF).
Param 45 slave node without making use of synchronization (deviation from
nominal bit rate)
F < ± 1,5 %
TOL_RES_SLAVE_B
For communication between any two nodes their bit rate shall not
differ by more than ± 2,0%.
Param 46 deviation of slave node bit rate from the nominal bit rate before
synchronization; relevant for nodes making use of synchronization F < ± 14 %
TOL_UNSYNCH_B
and direct break field detection.
87 Table 7 defines the bit rate deviation for slave nodes from master node in BR_Range_10K systems.
8 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
88 Table 7 — Bit rate deviation for slave nodes from master node in BR_Range_10K systems
Number BR_Range_10K bit rate deviation Name ΔF / F
MASTER
Param 47 Deviation of slave node bit rate from the master node bit rate after
synchronization; relevant for nodes making use of
F < ± 2,0 %
TOL_SYNCH_B
synchronization; any slave node shall stay within this deviation for
all fields of a frame which follow the sync byte field.
Param 48 For communication between any two nodes (i.e. data stream from
one slave to another slave) their bit rate shall not differ by more
than F . The following condition shall be checked
TOL_SLAVE_to_SLAVE
for:
a) |F - F | < F
TOL_RES_SLAVE_1 TOL_RES_SLAVE_2 TOL_SLAVE_to_SLAVE F < ± 2,0 %
TOL_SLAVE_to_SLAVE
b) |F - F | < F
TOL_SYNCH_1 TOL_SYNCH_2 TOL_SLAVE_to_SLAVE
c) |(F + F ) - F |
TOL_RES_MASTER_B TOL_SYNCH_1 TOL_RES_SLAVE_2
< F
TOL_SLAVE_to_SLAVE
90 5.2 Timing requirements
91 5.2.1 Bit timing
92 If not otherwise stated, all bit times in this document use the bit timing of the master node as a reference.
93 5.2.2 Synchronization procedure
94 The sync byte field consists of the fixed data 55 inside a byte field. The synchronization procedure shall be
95 based on time measurement between falling edges of the pattern. The falling edges are available in distances
96 of 2, 4, 6 and 8 bit times which allows a simple calculation of the basic bit times t .
BIT
97 Figure 1 shows the sync byte field.
Sync byte field
8 t
BIT
2 t 2 t 2 t 2 t
BIT BIT BIT BIT
start stop
2 4
0 1 3
5 6 7
bit bit
100 Figure 1 — Sync byte field
ISO/DIS 17987-4.2
102 5.2.3 Bit sample timing
103 The bits of a byte field shall be sampled according to the following specification. In Figure 2 the bit sample
104 timing of a byte field is illustrated. The corresponding timing parameters are listed in Table 8.
105 A byte field shall be synchronized at the falling edge of the start bit. The byte field synchronization (BFS) shall
106 have an accuracy of t .
BFS
107 All methods for start bit sampling that meet the byte field synchronization t are allowed.
BFS
108 After the byte field synchronization on the falling edge of the start bit the data bit itself shall be sampled within
109 the window between the earliest bit sample (EBS) time t and the latest bit sample (LBS) time t . The
EBS LBS
110 latest bit sample time t depends on the accuracy of the byte field synchronization t . The dependency
LBS BFS
111 between t and t is given in equation (1)
LBS BFS
Definition of equation (1)
t = 10/16 t - t
LBS BIT BFS
113 The following bits shall be sampled within the same range as the sample window of the first data bit with the
114 sample window repetition time t respectively. The sample window repetition time t is specified from the
SR SR
115 EBS of the former bit (n-1) to the EBS of the current bit; see equation (2).
Definition of equation (2)
t = t - t = t - t = t
SR EBS(n) EBS(n-1) LBS(n) LBS(n-1) BIT
117 Table 8 — Bit sample timing
Number Parameter Min. Typ. Max. Unit Comment / condition
Param 6 t --- 1/16 2/16 t Value of accuracy of the byte field detection
BFS BIT
Param 7 t 7/16 --- --- t Earliest bit sample time, t ≤ t
EBS BIT EBS LBS
Param 8 t
LBS --- --- --- tBIT Latest bit sample, see equation (1), tLBS ≥ tEBS
119 For devices, which make use of more than one sample per bit, the bit sample majority shall determine the bit
120 data. Furthermore, the sample majority shall be between the EBS and the LBS.
121 Table 9 defines the bit sample timing example.
122 Table 9 — Bit sample timing example
UART/SCI t t t = 10/16 t - t
BFS EBS LBS BIT BFS
cycles per tBIT
16 1/16 t 7/16 t 9/16 t
BIT BIT BIT
8 1/8 t (= 2/16 t ) 4/8 t (= 8/16 t ) 4/8 t (= 8/16 t )
BIT BIT BIT BIT BIT BIT
10 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
124 Figure 2 shows the bit sample timing.
Start Bit Bit 0 (LSB)
t
BFS
tEBS = 7/16 tBIT t = t - t = t
SR EBS(1) EBS(0) BIT
t = 10/16 t - t
LBS BIT BFS
Falling edge
EBS LBS
EBS LBS
of start bit
(1) (1)
(0) (0)
detected
Start Stop
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7
bit bit
Bit 7 Stop Bit
t = 7/16 t
EBS BIT
tLBS = 10/16 tBIT - tBFS
t
BIT
127 Figure 2 — Bit sample timing
129 5.3 Line driver/receiver
130 5.3.1 General configuration
131 The bus line driver/receiver is based on the ISO 9141 standard. It consists of the bidirectional bus line LIN
132 which is connected to the driver/receiver of every bus node, and is connected via a termination resistor and a
133 diode to the positive transceiver supply voltage V (see Figure 3). The diode is mandatory to prevent an
SUP
134 uncontrolled power supply of the ECU from the bus in case of a ’loss of battery’.
135 It is important to note that the LIN specification refers to the voltages at the external electrical connections of
136 the electronic control unit (ECU), and not to ECU internal voltages. In particular the parasitic voltage drops of
137 reverse polarity diodes have to be taken into account when designing a LIN transceiver circuit.
138 5.3.2 Definition of supply voltages for the physical interface
139 V denotes the supply voltage at the connector of the ECU. Electronic components within the unit may see
BAT
140 an internal supply V being different from V (see Figure 3). This can be the result of protection filter
SUP BAT
ISO/DIS 17987-4.2
141 elements and dynamic voltage changes on the bus. This has to be taken into consideration for the
142 implementation of semiconductor products for LIN.
V
Shift_BAT
ECU
D
Rev_Batt Transceiver IC
D
ser_int
Master only!
V V
BATTERY
BAT
D
ser_master
V
SUP
R
master
R
Slave
V
V BAT
BATTERY
R
X
LIN, V
BUS
T C , C
Slave Master
X
V
GND_BATTERY V
GND_ECU
V : Internal supply for electronics
SUP
C
Decoupling
V Voltage drop over the
Shift_GND
diodes in pull up path
V
BUS
V
BAT
V
SUP
V
BUSrec
V
BUSdom
t
145 Figure 3 — Illustration of the difference between external supply voltage V and the internal supply
BAT
146 voltage V
SUP
148 5.3.3 Signal specification
149 Figure 4 shows the voltage levels on the bus line.
driver node
receiver node
V V
SUP SUP
recessive recessive
60 %
40 %
dominant dominant
152 Figure 4 — Voltage levels on the bus line
12 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
153 For a correct transmission and reception of a bit, it has to be asserted that the signal is available with the
154 correct voltage level (dominant or recessive) at the bit sampling time of the receiver. Ground shifts as well as
155 drops in the supply voltage have to be taken into consideration as well as symmetry failures in the propagation
156 delay. Figure 5 shows the timing parameters that impact the behaviour of the LIN bus. The minimum and
157 maximum values of the different parameters are listed in the following tables.
t t t
BIT BIT BIT
TXD
(input to transmitting node)
t t
BUS_dom(max) BUS_rec(min)
thresholds of
TH
Rec(max)
receiving node 1
V
SUP
TH
Dom(max)
(transceiver supply of
transmitting node)
thresholds of
TH
Rec(min)
receiving node 2
TH
Dom(min)
t t
BUS_dom(min) BUS_rec(max)
RXD
(output of receiving node 1)
t
rx_pdf(1)
t
rx_pdr(1)
RXD
(output of receiving node 2)
t t
rx_pdr(2) rx_pdf(2)
Key
1 LIN bus signal
160 Figure 5 — Definition of bus timing parameters
ISO/DIS 17987-4.2
162 5.3.4 12 V LIN systems: electrical parameters
163 5.3.4.1 DC parameters
164 The electrical DC parameters of the LIN electrical physical layer and the termination resistors are listed in
165 Table 10 and Table 11, respectively. Unless otherwise specified, all voltages are referenced to the local ECU
166 ground and positive currents flow into the ECU.
167 In case of an integrated resistor/diode network no parasitic current paths shall be formed between the bus line
168 and the ECU-internal supply (V ), for example by ESD elements.
SUP
169 Table 10 defines the electrical DC parameters of the LIN electrical physical layer.
170 Table 10 — Electrical DC parameters of the LIN electrical physical layer
Number Parameter Min. Typ. Max. Unit Comment / condition
a
Param 9 8 --- 18 V ECU operating voltage range
V
BAT
b
Param 10 7,0 --- 18 V Supply voltage range
V
SUP
V
Param 11 SUP_NON_OP -0,3 --- 40 V Voltage range within which the device is not
destroyed; no guarantee of correct operation
c
Param 12 40 --- 200 mA Current limitation for driver dominant state
I
BUS_LIM
d
driver on V = V
BUS BAT_max
Param 13 I -1 --- --- mA Input leakage current at the receiver including
BUS_PAS_dom
pull-up resistor as specified in Table 11 Param
26 driver off
V = 0 V
BUS
V = 12 V
BAT
Param 14 I --- --- 20 µA Driver off
BUS_PAS_rec
8 V < V < 18 V
BAT
8 V < V < 18 V
BUS
V ≥ V
BUS BAT
Param 15 I -1 --- 1 mA Control unit disconnected from ground
BUS_NO_GND
GND = V
Device SUP
0 V < V < 18 V
BUS
V = 12 V
BAT
Loss of local ground shall not affect
communication in the residual network.
Param 16 I --- --- 100 µA V disconnected
BUS_NO_BAT BAT
V = GND
SUP
0 < V < 18 V
BUS
Node has to sustain the current that can flow
under this condition. Bus shall remain
operational under this condition.
Param 17 VBUSdom --- --- 0,4 V Receiver dominant state
SUP
Param 18 V 0,6 --- --- V Receiver recessive state
BUSrec SUP
e
V
Param 19 BUS_CNT 0,475 0,5 0,525 V
SUP VBUS_CNT = (Vth_dom + Vth_rec) / 2
Param 20 V --- --- 0,175 V V = V - V
HYS SUP HYS th_rec th_dom
14 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
Number Parameter Min. Typ. Max. Unit Comment / condition
Param 21 V 0,4 0,7 1,0 V Voltage drop at the serial diodes
SerDiode
D and D in pull-up path
ser_master Rev_Batt
f
(Figure 3). V = V - V
SerDiode ANODE CATHODE
Param 22 V 0 --- 11,5 % V Battery shift
Shift_BAT BAT
g
V = V - V - V
Shift_BAT BATTERY Shift_GND BAT
Param 23 V 0 --- 11,5 % V GND shift
Shift_GND BAT
g
V = V - V
Shift_GND GND_ECU GND_BATTERY
h
Param 24 0 --- 8 % V Difference between battery shift and GND shift
V BAT
Shift_Difference
V = |V - V |
Shift_Difference Shift_BAT Shift_GND
Param 82 V -27 --- 40 V The part should not suffer any damage
BUS_MAX_RATINGS
a
V denotes the supply voltage at the connector of the control unit and may be different from the internal supply
BAT
V for electronic components (see 5.3.2).
SUP
b
V denotes the supply voltage at the transceiver inside the control unit and may be different from the external
SUP
supply V for control units (see 5.3.2).
BAT
c
I : Current flowing into the node.
BUS
d
A transceiver shall be capable to sink at least 40mA. The maximum current flowing into the node shall not exceed
200 mA under DC conditions to avoid possible damage.
e
V : receiver threshold of the recessive to dominant LIN bus edge. V receiver threshold of the dominant to
th_dom th_rec:
recessive LIN bus edge.
f
V : voltage at the anode of the diode. V : voltage at the cathode of the diode.
ANODE CATHODE
g
V : voltage across the vehicle battery connectors. V : voltage on the local ECU ground connector with
BATTERY GND_ECU
respect to vehicle battery ground connector (V ).
GND_BATTERY
h
This constraint refers to duty cycle D1 and D2 only.
174 Table 11 defines the parameters of the pull-up resistors.
175 Table 11 — Parameters of the pull-up resistors
Number Parameter Min. Typ. Max. Unit Comment / condition
Param 25 R 900 1000 1100 Ω The serial diode is mandatory (see Figure 3).
MASTER
Param 26 R 20 30 60 KΩ The serial diode is mandatory.
SLAVE
177 5.3.4.2 AC parameters
178 The electrical AC parameters of the LIN electrical physical layer are listed in Table 12, Table 13, and
179 Table 14, with the parameters being defined in Figure 5. The electrical AC characteristics of the bus can be
180 strongly affected by the line characteristics as shown in 5.3.3. The time constant τ (and thus the overall
181 capacitance) of the bus (see 5.3.5) has to be selected carefully in order to allow for a correct signal
182 implementation under worst case conditions.
ISO/DIS 17987-4.2
183 Table 12 specifies the timing parameters for proper operation at 20 kbit/s.
184 Table 12 — Driver electrical AC parameters of the LIN electrical physical layer of BR_Range_20K 12 V
185 LIN networks
Number Parameter Min. Typ. Max. Unit Comment / condition
LIN driver, bus load conditions (C ; R ): 1 nF; 1 kΩ / 6,8 nF; 660 Ω / 10 nF; 500 Ω
BUS BUS
Param 27 D1 0,396 --- --- --- TH = 0,744 x V ;
Rec(max) SUP
(Duty Cycle 1)
TH = 0,581 x V ;
Dom(max) SUP
V = 7,0 V to 18 V; t = 50 µs;
SUP BIT
D1 = t / (2 x t )
Bus_rec(min) BIT
Param 28 D2 --- --- 0,581 --- TH = 0,422 x V ;
Rec(min) SUP
(Duty Cycle 2)
TH = 0,284 x V ;
Dom(min) SUP
V = 7,6 V to 18 V; t = 50 µs;
SUP BIT
D2 = t / (2 x t )
Bus_rec(max) BIT
187 For improved EMC performance, exception is granted for speeds of 10,417 kbit/s or below. For details see
188 Table 13, which specifies the timing parameters for proper operation at 10,417 kbit/s.
189 Table 13 — Driver electrical AC parameters of the LIN electrical physical layer of BR_Range_10K 12 V
190 LIN networks
Number Parameter Min. Typ. Max. Unit Comment / condition
LIN driver, bus load conditions (C ; R ): 1 nF; 1 kΩ / 6,8 nF; 660 Ω / 10 nF; 500 Ω
BUS BUS
Param 29 D3 0,417 --- --- --- TH = 0,778 x V
Rec(max) SUP;
(Duty Cycle 3)
TH = 0,616 x V
Dom(max) SUP;
V = 7,0 V to 18 V; t = 96 µs;
SUP BIT
D3 = t / (2 x t )
Bus_rec(min) BIT
Param 30 D4 --- --- 0,590 --- TH = 0,389 x V ;
Rec(min) SUP
(Duty Cycle 4)
TH = 0,251 x V ;
Dom(min) SUP
V = 7,6 V to 18 V; t = 96 µs;
SUP BIT
D4 = t / (2 x t )
Bus_rec(max) BIT
192 Application specific implementations (ASICs) shall meet the parameters in Table 12 and/or Table 13. If both
193 sets of parameters are implemented, the proper mode shall be selected based on the bus bit rate.
194 Table 14 defines the receiver electrical AC parameters of the LIN electrical physical layer.
195 Table 14 — Receiver electrical AC parameters of the LIN electrical physical layer
Number Parameter Min. Typ. Max. Unit Comment / condition
LIN receiver, RXD load condition (C ): 20 pF; (if open drain behaviour: R = 2,4 kΩ)
RXD pull_up
Param 31 trx_pd --- --- 6 µs propagation delay of receiver
Param 32 trx_sym -2 --- 2 µs symmetry of receiver propagation delay rising
edge with respect to falling edge
16 © ISO 2015 – All rights reserved

ISO/DIS 17987-4.2
197 The EMC behaviour of the LIN bus depends on the signal shape represented by slew rate and other factors
198 such as di/dt and d²V/dt². The signal shape should be carefully selected in order to reduce emissions and
199 allow for bit rates up to 20 kbit/s.
200 5.3.5 24V LIN systems: electrical parameters
201 5.3.5.1 DC parameters
202 The electrical DC parameters of the LIN electrical physical layer and the termination resistors are listed in
203 Table 15 and Table 16, respectively. Unless otherwise specified, all voltages are referenced to the local ECU
204 ground and positive currents flow into the ECU.
205 In case of an integrated resistor/diode network no parasitic current paths shall be formed between the bus line
206 and the ECU-internal supply (V ), for example by ESD elements.
SUP
207 Table 15 defines the electrical DC parameters of the LIN electrical physical layer.
208 Table 15 — Electrical DC parameters of the LIN electrical physical layer
Number Parameter Min. Typ. Max. Unit Comment / condition
Param 52 V 16 --- 36 V ECU operating voltage range in
BAT_BR_Range_20K
a
BR_Range_20K 24 V LIN systems
Param 53 V 15 --- 36 V supply voltage range in BR_Range_20K 24 V
SUP_BR_Range_20K
b
LIN systems
V
Param 54 BAT_BR_Range_10K 8 --- 36 V operating voltage range in BR_Range_10K
a
24 V LIN systems
Param 55 V 7 --- 36 V supply voltage range in BR_Range_10K 24 V
SUP_BR_Range_10K
b
LIN systems
Param 56 V -0,3 --- 58 V voltage range within which the device is not
SUP_NON_OP
destroyed; no guarantee of correct operation
c
Param 57 75 --- 300 mA current limitation for driver dominant state
I
BUS_LIM
d
driver on V = V
BUS BAT_max
Param 58 I -2 --- --- mA input leakage current at the receiver including
BUS_PAS_dom
pull-up resistor as specified in Table 16 Param
71 driver off V = 0 V
BUS
V = 24 V
BAT
Param 59 I --- --- 20 µA driver off
BUS_PAS_rec
8 V < V < 36 V
BAT
8 V < V < 36 V
BUS
V ≥ V
BUS BAT
Param 60 I -2 --- 2 mA control unit disconnected from ground
BUS_NO_GND
GND = V
Device SUP
0 V < V < 36 V
BUS
V = 24 V
BAT
loss of local ground shall not affect
communication in the residual network.
Param 61 I --- --- 100 µA V disconnected
BUS_NO_BAT BAT
V = GND
SUP
0 < V < 36 V
BUS
node has to sustain the current that can flow
under this condition. Bus shall remain
operational under this condition.
ISO/DIS 17987-4.2
Param 62 V --- --- 0,4 V receiver dominant state
BUSdom SUP
Param 63 V 0,6 --- --- V receiver recessive state
BUSrec SUP
e
V
Param 64 BUS_CNT 0,475 0,5 0,525 VSUP
V = (V + V ) / 2
BUS_CNT th_dom th_rec
Param 65 V --- --- 0,175 V V = V - V
HYS SUP HYS th_rec th_dom
Param 66 V 0,4 0,7 1,0 V voltage drop at the serial diodes
SerDiode
D and D in pull-up path (Figure 3).
ser_master ser_int
f
V = V - V
SerDiode ANODE CATHODE
V
Param 67 Shift_BAT 0 --- 11,5 % V battery-shift
BAT
g
V = V - V - V
Shift_BAT BATTERY Shift_GND BAT
Param 68 V 0 --- 11,5 % V GND-shift
Shift_GND BAT
g
V = V - V
Shift_GND GND_ECU GND_BATTERY
h
Param 69 0 --- 8 % V difference between battery-shift and GND-shift
BAT
V
Shift_Difference
V = |V - V |
Shift_Difference Shift_BAT Shift_GND
Param 83 V 6 --- 36 V The part should not suffer any damage
BUS_MAX_RATINGS
Number
...
