Geographic information — Building information modelling (BIM) to
geographic information systems (GIS) conceptual mapping (B2GM)
1 Scope
This document defines the conceptual framework and mechanisms for mapping information elements from
Building Information Modellingbuilding information modelling (BIM) to Geographic Information
Systemsgeographic information systems (GIS) to access the required information based on specific user
requirements.
The conceptual framework for mapping BIM information to GIS is defined with the following three mapping
mechanisms:
— BIM to GIS Perspective Definitionperspective definition (B2G PD);
— BIM to GIS Element Mappingelement mapping (B2G EM);
— BIM to GIS level of detail (LOD Mapping) mapping (B2G LM).
This document does not describe physical schema integration or mapping between BIM and GIS models
because the physical schema integration or mapping between two heterogeneous models is very complex and
can cause a variety of ambiguity problems (see Annex D.). Developing a unified information model between
BIM and GIS is a desirable goal, but it is out of the scope of this document.
The scope of thisThis document includesis applicable to the following concepts:
— definition for BIM to GIS conceptual mapping requirement description;
— definition of BIM to GIS conceptual mapping framework and component;
— definition of mapping for export from one schema into another.
The This document does not apply to the following concepts are outside the scope:
— definition of any particular mapping application
...
