IEC 60691:2015/COR1:2016
(Corrigendum)Corrigendum 1 - Thermal-links - Requirements and application guide
General Information
- Abstract
Provides general rules for all electrotechnical components installed in power circuits, control and indicating circuits on rail rolling stock. It supplements the rules given in part 1 of IEC 60077. This part and the part 1 replaces IEC 60077 published in 1968.
- Status
- Published
- Publication Date
- 11-Aug-2016
- Technical Committee
- SC 32C - Miniature fuses
- Current Stage
- DELPUB - Deleted Publication
- Start Date
- 06-Mar-2023
- Completion Date
- 28-Aug-2026
Relations
- Effective Date
- 05-Sep-2023
- Effective Date
- 05-Sep-2023
Get Certified
Connect with accredited certification bodies for this standard
IMQ S.p.A. (Certification)
Italian electrical product certification.
IRIS Certification (UNIFE)
International Railway Industry Standard certification.
SLG Prüf- und Zertifizierungs GmbH
German testing and certification body.
Sponsored listings
Frequently Asked Questions
IEC 60691:2015/COR1:2016 is a standard published by the International Electrotechnical Commission (IEC). Its full title is "Corrigendum 1 - Thermal-links - Requirements and application guide". This standard covers: Provides general rules for all electrotechnical components installed in power circuits, control and indicating circuits on rail rolling stock. It supplements the rules given in part 1 of IEC 60077. This part and the part 1 replaces IEC 60077 published in 1968.
Provides general rules for all electrotechnical components installed in power circuits, control and indicating circuits on rail rolling stock. It supplements the rules given in part 1 of IEC 60077. This part and the part 1 replaces IEC 60077 published in 1968.
IEC 60691:2015/COR1:2016 is classified under the following ICS (International Classification for Standards) categories: 29.120.50 - Fuses and other overcurrent protection devices; 45.060 - Railway rolling stock. The ICS classification helps identify the subject area and facilitates finding related standards.
IEC 60691:2015/COR1:2016 has the following relationships with other standards: It is inter standard links to IEC 60691:2015, IEC 60691:2023. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
IEC 60691:2015/COR1:2016 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
IEC 2016
INTERNATIONAL ELECTROTECHNICAL COMMISSION
COMMISSION ÉLECTROTECHNIQUE INTERNATIONALE
____________
IEC 60691 IEC 60691
Edition 4.0 2015-10 Édition 4.0 2015-10
Thermal-links – Requirements and application Protecteurs thermiques – Exigences et guide
guide d'application
CORRIGENDUM 1
Corrections to the French version appear after the English text.
Les corrections à la version française sont données après le texte anglais.
Replace the existing Table 1 with the following new Table:
IEC 60691:2015-10/COR1:2016-08(en-fr)
– 2 – IEC 60691:2015/COR1:2016
IEC 2016
Table 1 – Test schedule
Clause or Test Specimen groups
Sub-clause
A B C D E F G H I J K
a Marking (Rub test) X X
a Marking (visual inspection only) X X
9 Constructional requirements
a Tensile forces X
9.2.2
a Thrust force X
9.2.3
a Bending/twist force X
9.2.4
a Resistance to tracking X
9.6
a Creepage distances and clearances X X
9.7
9.8 Temperature and humidity cycle X X X X X
conditioning
10 Electrical requirements
10.1 Dielectric strength (if applicable) X X X X X
10.2 Insulation resistance (if applicable) X X X X X
10.3 Interrupting current X X
10.4 Transient overload current X X X
11 Temperature tests
11.2 Check on T X
h
11.3 Check on T X X
f
11.4 Check on T followed by dielectric X X
m
test and insulation resistance
11.5 Ageing X X X X X
step 1 (optional) 21 days
step 2 (mandatory) 21 days
step 3 (mandatory) 14 days
step 4 (mandatory) 7 days
step 5 (mandatory) 7 days
step 6 (mandatory) 24 hours
10.1 Dielectric strength X X X X X X X X
10.2 Insulation resistance X X X X X X X X
12 Resistance to rusting
a Resistance to rusting (ferrous parts) X X X
If the conditions of voltage, power and current in 10.3.2.3, 10.3.2.4 and 10.3.2.5 are not covered by one test,
a
...
