EN 1264-5:2008

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Ploskovni sistemi za gretje in hlajenje z vodo - 5. del: Grelne in hladilne površine, vgrajene v tla, strop ali stene - Ugotavljanje oddaje toploteRaumflächenintegrierte Heiz und Kühlsysteme mit Wasserdurchströmung - Teil 5: Heiz­ und Kühlflächen in Fußböden, Decken und Wänden - Bestimmung der Wärmeleistung und der KühlleistungSystèmes de surfaces chauffantes et refraîchissantes hydrauliques intégrées - Partie 5: Surfaces chauffantes et refraîchissantes intégrées dans les sols, les plafonds et les murs - Détermination de l'emission thermiqueWater based surface embedded heating and cooling systems - Part 5: Heating and cooling surfaces embedded in floors, ceilings and walls - Determination of the thermal output91.140.10Sistemi centralnega ogrevanjaCentral heating systemsICS:Ta slovenski standard je istoveten z:EN 1264-5:2008SIST EN 1264-5:2009en,fr,de01-januar-2009SIST EN 1264-5:2009SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1264-5October 2008ICS 91.140.10 English VersionWater based surface embedded heating and cooling systems -Part 5: Heating and cooling surfaces embedded in floors,ceilings and walls - Determination of the thermal outputSystèmes de surfaces chauffantes et refraîchissanteshydrauliques intégrées - Partie 5: Surfaces chauffantes etrefraîchissantes intégrées dans les sols, les plafonds et lesmurs - Détermination de l'emission thermiqueRaumflächenintegrierte Heiz
und Kühlsysteme mitWasserdurchströmung - Teil 5: Heiz- und Kühlflächen inFußböden, Decken und Wänden - Bestimmung derWärmeleistung und der KühlleistungThis European Standard was approved by CEN on 13 September 2008.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2008 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1264-5:2008: ESIST EN 1264-5:2009

Introduction This draft European Standard is based on the realisation that in the field of commercial trade the thermal output of heating and cooling systems represents the basis of rating. In order to be able to evaluate and compare different heating and cooling systems, it is, therefore, necessary to refer to values determined using one single, unambiguously defined method. The basis for doing so are the prove methods for the determination of the thermal output of floor heating systems described in Part 2 of this European Standard. In analogy to the European Standard EN 442-2 (Radiators and convectors — Part 2: Test methods and rating), this prove method provides characteristic partial load curves under defined boundary conditions as well as the characteristic output of the system represented by the standard thermal output together with the associated standard temperature difference between the heating medium and the room temperature. SIST EN 1264-5:2009

1 Scope This European Standard applies to water based heating and cooling systems embedded into the enclosure surfaces of the room to be heated or to be cooled. Part 5 of this standard deals with the recalculation of values determined in Part 2 of this European Standard for the system in question, using it for floor heating applications. The recalculation method described in this part of the standard enables the conversion of the calculation and test results of Part 2 into results for other surface orientations in the room, i.e. for ceiling and wall heating, as well as for the application as cooling surfaces, i.e. for floor, ceiling and wall cooling. It has to be emphasised that the test results of Part 2 of this European Standard are the basis of all calculation. Therefore the use of this prove method is necessary whether or not the system in question is used for heating or cooling application. This European Standard shall be applied to commercial trade and practical engineering if proved and certifiable values of the thermal output shall be used.
2 Normative References The following referenced documents are indispensable for the application of this document. For dated references, only t
...
