EN ISO 1872-1:1999

SLOVENSKI STANDARD
01-maj-2000
3ROLPHUQLPDWHULDOL3ROLHWLOHQVNLPDWHULDOL]DREOLNRYDQMHLQHNVWUXGLUDQMHGHO
6LVWHPR]QDþHYDQMDLQSRGODJH]DVSHFLILNDFLMH,62
Plastics - Polyethylene (PE) moulding and extrusion materials - Part 1: Designation
system and basis for specifications (ISO 1872-1:1993)
Kunststoffe - Polyethylen (PE)-Formmassen - Teil 1: Bezeichnungssystem und Basis für
Spezifikationen (ISO 1872-1:1993)
Plastiques - Polyéthylene (PE) pour moulage et extrusion - Partie 1: Systeme de
désignation et base de spécification (ISO 1872-1:1993)
Ta slovenski standard je istoveten z: EN ISO 1872-1:1999
ICS:
83.080.20 Plastomeri Thermoplastic materials
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

INTERNATIONAL IS0
1872-I
STANDARD
Second edition
1993-l 2-15
Plastics - Polyethylene (PE) moulding and
extrusion materials -
Part 1:
Designation system and basis for
specifications
P/as tiques - PO/y&h y/&e (PE) pour moulage et extrusion -
Partie I: Sys t&me de d&igna tion et base de spkification
Reference number
IS0 1872-l : 1993(E)
IS0 1872=1:1993(E)
Foreword
IS0 (the International Organization for Standardization) is a worldwide
federation of national standards bodies (IS0 member bodies). The work
of preparing International Standards is normally carried out through IS0
technical committees. Each member body interested in a subject for
which a technical committee has been established has the right to be
represented on that committee. International organizations, governmental
and non-governmental, in liaison with ISO, also take part in the work. IS0
collaborates closely with the International Electrotechnical Commission
(I EC) on all matters of electrotechnical standardization.
Draft International Standards adopted by the technical committees are
circulated to the member bodies for voting. Publication as an International
Standard requires approval by at least 75 % of the member bodies casting
a vote.
International Standard IS0 1872-1 was prepared by Technical Committee
lSO/TC 61, Plastics, Sub-Committee SC 9, Thermoplastic materials.
This second edition cancels and replaces the first edition
(IS0 1872-l :1986), which has been brought into accordance with the re-
vised frame text for designation standards.
IS0 1872 consists of the following parts, under the general title
P/as tics - Polyethylene (PE) moulding and extrusion materials:
- Part I: Designation system and basis for specifications
- Part 2: Preparation of test specimens and determination of proper-
ties
0 IS0 1993
All rights reserved. No part of this publication may be reproduced or utilized in any form or
by any means, electronic or mechanical, including photocopying and microfilm, without per-
mission in writing from the publisher.
International Organization for Standardization
Case Postale 56 l CH-1211 Geneve 20 l Switzerland
Printed in Switzerland
ii
IS0 1872=1:1993(E)
INTERNATIONAL STANDARD
Plastics - Polyethylene (PE) moulding and extrusion
materials -
Part I:
Designation system and basis for specifications
1 Scope
1.1 This part of IS0 1872 establishes a system of designation for polyethylene thermoplastic material, which
may be used as the basis for specifications.
1.2 The types of polyethylene plastic are differentiated from each other by a classification system based on ap-
propriate levels of the designatory properties
a) density
b) melt mass-flow rate
and on information about the intended application and/or method of processing, important properties, additives,
colorants, fillers and reinforcing materials.
1.3 This part of IS0 1872 is applicable to all polyethylene homopolymers and to copolymers of ethylene having
a content of other I-olefinic monomers of less than 50 % (m/m) and a content of non-olefinic monomers with
functional groups up to a maximum of 3 % (m/m).
It applies to materials ready for normal use in the form of powder, granules or pellets, unmodified or modified by
colorants, additives, fillers, etc.
This part of IS0 1872 does not apply to masterbatches or to EPM rubber.
1.4 It is not intended to imply that materials having the same designation give necessarily the same perform-
ance. This part of IS0 1872 does not provide engineering data, performance data or data on processing conditions
which may be required to specify a material for a particular application and/or method of processing.
If such additional properties are required, they shall be determined in accordance with the test methods specified
in part 2 of this International Standard, if suitable.
1.5 In order to specify a thermoplastic material for a particular application or to ensure reproducible processing,
additional requirements may be given in data block 5 (see clause 3, introductory paragraph).
IS0 1872=1:1993(E)
2 Normative references
The following standards contain provisions which, through reference in this text, constitute provisions of this part
of IS0 1872. At the time of publication, the editions indicated were valid. All standards are subject to revision, and
parties to agreements based on this part of IS0 1872 are encouraged to investigate the possibility of applying the
most recent editions of the standards indicated below, Members of IEC and IS0 maintain registers of currently
valid International Standards.
IS0 1043-l : 1987, Plastics - Symbols - Part 1: Basic polymers and their special characteristics.
Determination of the melt mass-flow rate (MFR) and the melt volume-flow rate (MVR)
IS0 1133:1991, Plastics -
of thermoplastics.
IS0 1183:1987, Plastics - Methods for determining the density and relative density of non-cellular plastics.
IS0 1872-2: 1989, Plastics - Polyethylene (PE) and ethylene copolymer thermoplastics - Part 2: Preparation of
test specimens and determination of properties.
3 Designation and specification system
The designation and specification system for thermoplastics is based on the following standardized pattern:
Designation
Identity block
Description block Individual-item block
(optional)
International Stan-
dard number block
Data block Data block Data block Data block
Data block
3 4 5
1 2
\
,
The designation consists of an optional description block, reading “Thermoplastics”, and an identity block com-
prising the International Standard number and an individual-item block. For unambiguous designation, the
individual-item block is subdivided into five data blocks comprising the following information:
Data block 1: Identification of the plastic by its symbol PE in accordance with IS0 1043-l (see 3.1).
Data block 2: Position 1: Intended application or method of processing (see 3.2).
Positions 2 to 8: Important properties, additives and supplementary information (see 3.2).
Data block 3: Designatory properties (see 3.3).
Data block 4: Fillers or reinforcing materials and their nominal content (see 3.4).
Data block 5: For the purpose of specifications, a fifth data block may be added containing additional infor-
mation.
The first character of the individual-item block shall be a hyphen. The data blocks shall be separated from each
other by commas.
If a data block is not used, this shall be indicated by doubling the separation sign, i.e. by two commas (,,L
3.1 Data block 1
In this data block, after the hyphen, polyethylene plastics are identified by the symbol “PE”, in accordance with
IS0 1043-I.
IS0 1872=1:1993(E)
3.2 Data block 2
In this data block, information about the intended application and/or method of processing is given in position 1
and information about important properties, additives and colour in positions 2 to 8. The code-letters used are
specified in table 1.
If information is presented in positions 2 to 8 and no specific informa
...
