EN 14420-7:2013 is a standard published by the European Committee for Standardization (CEN). Its full title is "Hose fittings with clamp units - Part 7: Cam locking couplings". This standard covers: This European Standard specifies the design, materials, dimensions and marking requirements for cam locking couplings that serve as the link between hoses and connections to transport liquids, solids and gases, except liquid gas and steam. The couplings are capable of operating the pressure range -0,8 bar ) to 16 bar working pressure (for aluminium-cast-materials -0,8 bar to 10 bar) in a working temperature range of -20 °C up to +65 °C.
This European Standard specifies the design, materials, dimensions and marking requirements for cam locking couplings that serve as the link between hoses and connections to transport liquids, solids and gases, except liquid gas and steam. The couplings are capable of operating the pressure range -0,8 bar ) to 16 bar working pressure (for aluminium-cast-materials -0,8 bar to 10 bar) in a working temperature range of -20 °C up to +65 °C.
EN 14420-7:2013 is classified under the following ICS (International Classification for Standards) categories: 23.040.70 - Hoses and hose assemblies. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 14420-7:2013 has the following relationships with other standards: It is inter standard links to EN 14420-7:2004+A1:2007, EN 14420-7:2022, ISO 272:1982, EN 1706:2020+A1:2021, EN 12420:2024, EN 1264-3:1997, EN ISO 683-1:2018, EN 755-2:2025, EN 22768-1:1993, EN 1982:2024, EN 14420-1:2013, EN ISO 8330:2008, EN 14420-5:2013, EN ISO 228-1:2003, EN 10213:2007+A1:2016. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
